BLADE REPLACEMENT
1
5
6
7
8
5. Remove the flat washer between the two
blades.
6. Using a wrench, loosen the nut and
the adjustment screw by turning it
anticlockwise.
7. Remove the stamping connector from
the steel wire, adjustment screw and nut
by pulling the blade away.
8. Replace the blade and flat washer.
To Next Page
