ASSEMBLY
MOUNTING THE SAFETY BAR ADDING THE TOOL
Align the safety bar into the the seat on the safety
device spindle.
Fasten the nylock nut using the spanner supplied.
Secure as shown.
Align the engine drive shaft into the seat on the
auger bit.
Secure using the gudgeon pin and cotter pin
supplied.
Your post hole digger is supplied with a 300mm
extension shaft to be used for deeper hole digging.
Figure 3
Figure 4
Figure 5
Figure 7
Figure 6
Figure 8
DO NOT start digging a hole with the extension shaft
attached.
