OPERATION
4
Correct operating position is with the two handles
bellow waist level, which will ensure full control of
the digger can be maintained.
Have your left foot slightly further forward than your
right foot to enable the frame near the safety bar to
rest against your left thigh. Always firmly grip the
handles with two hands when operating the unit.
DO NOT operate with either
one or two handles above waist
level.
The safety bar is designed to prevent
excessive rotation of the auger when the bit
is jammed, enabling the user to maintain
balance during operation.
Figure 10
Figure 11
Figure 12
Figure 13
HANDLE LEVEL
ROTATION
STOP
SAFETY BAR
ACT
