GUDGEON PIN AND COTTER PIN
The gudgeon pins and cotter pins secure the attachments to the drive shaft.
PRIMER BULB
The primer bulb is used to prime the carburetor prior to cold starting or if the unit has not been
used for a while.
RECOIL STARTER GRIP
The recoil starter grip is used (along with the engine switch) to start the engine.
THROTTLE LOCK
The throttle lock is used to help the engine on cold starts.
THROTTLE TRIGGER
The throttle trigger helps the operator control the speed of the auger to suit various ground
conditions.
TRIGGER LOCK
The trigger lock prevents the operator from accidently activating the throttle trigger. The trigger
lock must be depressed before applying the throttle.
SPECIFICATIONS
Model: RPHD52
Clutch engagement speed: 3900±200 rpm
Air cooled 2-stroke
Maximum engine speed:
8800±200 rpm
Engine displacement: 51.7 cc
50:1
W
eight: 9.5 kg
1.46 kw / 6500 rpm
Fuel tank volume: 0.95 L
Gearbox reduction ratio: 40:1
Auger diameter: 200mm
Auger speed: 200 - 230 rpm
Auger length: 740mm
Idle speed: 2800±200 rpm
Specifications are subject to change without notice.
SAFETY DEVICE CONTROL BOX AND SAFETY BAR
The patent safety device control box & safety bar prevent engine head assembly backward
rotation in the case of jammed dill.
Engine type:
Fuel mix ratio:
Engine power: 8800±200 rpm
11
ASSEMBLY
UNPACKING
Carefully remove the tool and any accessories from the carton. Make sure that all items listed
in the packing list are included.
Extension shaft: 300mm
To Next Page
