Inspect the tool carefully to make sure no breakage or damage occurred during shipping.
Do not discard the packing material until you have carefully inspected and satisfactorily
operated the tool.
WARNING!
If any parts are missing do not operate this tool until the missing parts are replaced.
Failure to do so could result in possible serious injury.
WARNING!
Do not attempt to modify this tool or create accessories not recommended for use with
this tool. Any such alteration or modification is misuse and could result in a hazardous
condition leading to possible serious personal injury.
FITTING THE AUGER BITS
See figure 6 & 7
Align the engine drive shaft into the seat on the auger bit and secure it using the appropriate
gudgeon pin and cotter pin provided.
NOTE: Your post hole digger is supplied with a 300mm extension shaft to be used for
deeper hole digging. DO NOT start digging a hole with the extension attached.
The hole should always be started with the auger bit only fitted. Once the hole is deep
enough and the support frame is at least 300mm below waist level, you may stop
the unit and attach the extension shaft between the engine assembly and the auger bit
for added comfort and deeper hole depth. (see figure 8)
WORKING RULES
WARNING!
Always follow the safety rules. The post hole digger must only be used to drill ground.
Do not lock the digger onto fixed supports. It is forbidden to apply tools or
applications other than the ones indicated and approved by the manufacturer.
MOUNTING THE SAFETY BAR
See figure 3, 4 & 5
Remove the nylon lock nut on the safety bar, align the bar shaft into the seat on the safety device
control box spindle, fasten the nylon lock nut using the supplied spanner.
OPERATION
12
WARNING!
Make sure engine is turned off, disconnect spark plug, before assembly.
