PRODUCT DESCRIPTION
1
LEGEND
1. Fuel tank
2. Engine switch
3. Throttle lock
4. Trigger lock
5. Starter grip
6. Throttle trigger
7. Right hand grip
1
2
3 4
5
6
7
8
9
10
111213
14
15
16
17
19
20
18
7
8
19
14
21
22
2324
8. Fuel cap
9. Support frame
10. Primeer bulb
11. Air box
12. Air box lock knob
13. Safety device control box
14. Safety bar
15. Idle speed adjusting screw
16. Choke lever
17. Spark plug cap
18. Left hand grip
19. Heat deflector grille
20. Engine cover
21. Throttle cable
22. Gear box
23. Gudgeon pin and
cotter pin
24. Drive shaft
Figure 1
