3
ENGLISH
Fig.2
1. Pole
2. Button
3. Collar
4. Threaded Base
5. Cord
6. Intermediate Pole
7. Powerhead Pole
8. Strap Hanger
9. Handle Grip
Fig.3
1. Chain Lubricant
2. Oil Reservoir Cap
3. Quick View Oil Window
Figure 4:
1. Lock-Off Button
2. Switch Trigger
3. Cord Retainer
Figure 5:
1. Collar
Figure 6:
1. First Cut. ¼ Diameter
2. Second Cut
3. Final Cut
Figure 7:
1. Cutting Guide
Figure 10:
1. Flats
Figure 12:
1. Drivecase Cover
2. Chain
3. Bar
4. Bar Nut
Figure 13:
1. Sprocket
2. Chain Tensioning Pin
3. Bar Stud
4. Bar
5. Bar Stud Slot
6. Chain Tensioning Pin Hole
7. Bar Nut
8. Drivecase Cover
Figure 14:
1. Sprocket
2. Chain Rotation
3. Chain
4. Chain Tensioning Screw
Figure 15:
1. Bar Nut
Figure 16:
1. Remove Cap
2. Bar Lube
3. Reservoir
Figure 18:
1. Top Plate
2. Cutting Corner
3. Side Plate
4. Depth Gauge
5. Toe
6. Gullet
7. Heel
8. Rivet Hole
Figure 21:
1. Left Hand Cutters
2. Right Hand Cutters
Figure 22:
1. Blade Cover
ASSEMBLY
UNPACKING
This product requires assembly.
n Carefully remove the product and any accessories
from the box. Make sure that all items listed in the
packing list are included.
n Inspect the product carefully to make sure no
breakage or damage occurred during shipping.
n Do not discard the packing material until you have
carefully inspected and satisfactorily operated the
product.
n If any parts are damaged or missing, please contact
Customer Service on:
(AUS) 1300 557 442
(NZ) 9573 0230
PACKING LIST
n Pole Saw
n Blade Cover
n Operator’s Manual
