6
RYOBI 10 in. TABLE SAW – MODEL NUMBER RTS10
The model number will be found on a label attached to the cabinet. Always mention the model number in all correspondence regarding your 10 in.
TABLE SAW or when ordering parts.
PARTS LIST FOR FIGURE B
1 089037007037 Cabinet ........................................................... 1
2 080015001473 Screw (M4 x 7 mm, Flat Hd.) .......................... 6
3 089037007904 Front Panel Label ............................................ 1
4 080015001475 Washer (D6.5 x D16x 2t) ................................. 1
5 080015001455 Hex Nut (1/4-20) ............................................. 1
6 089037007038 Lock Lever ...................................................... 1
7 411071001 Washer (D1/4 x D16 x 1t) ................................ 2
8 0101140904 Spring ............................................................. 1
9 089037007039 Lock Button .................................................... 1
10 089037007040 Hand Wheel Cap ............................................. 1
11 0101140203 Screw (Special, Handwheel) ........................... 1
12 0152010204 Handle Knob ................................................... 1
13 412011712 Washer (D1/4 x D13 x 1.5t) ............................ 1
14 089037007041 Hand Wheel .................................................... 1
15 411072702 Lock Washer (D1/4-20) ................................... 1
16 414011003 Spring Pin (D4 x 16 mm) ................................. 1
17 089037007042 Elevating Shaft (3/8-16 x 137 mm) ................. 1
18 410601004 Screw (M4 x 18 mm) ....................................... 4
19 089037007901 Warning Label ................................................. 1
20 984406003 Switch Key ...................................................... 1
21 089110109712 Switch Assembly (Inc. Key No. 20) ................. 1
22 089037007044 Plate ................................................................ 1
23 0101040203 Cord Clamp .................................................... 1
24 410192002 Screw (M4 x 16 mm, Pan Hd.) ........................ 2
25 080015001486 Screw (M6 x 25 mm, Cheese Hd.) .................. 5
26 089037007905 Data Label ....................................................... 1
27 0000120817 Screw (M8 x 19 mm, Pan Hd.) ........................ 3
28 0131010210 Cord Clamp .................................................... 1
29 089037007046 Switch Box ..................................................... 1
30 0121010235 Power Cord Bushing (Grommet) ..................... 1
31 089037007045 Power Cord ..................................................... 1
32 089037007902 Warning Label ................................................. 1
33 089037007105 Bolt (1/4-20 x 1-3/8 in.) ................................... 4
34 411062701 Nut (1/4-20 x 10 mm, Cheese Hd.) ................. 4
35 089037007708 Stand Assembly
(Inc. Key Nos. 1-8, See Figure C) ................... 1
KEY PART
NO. NUMBER DESCRIPTION QTY
KEY PART
NO. NUMBER DESCRIPTION QTY
