Ryobi RTS721S - DESCRIPTION; Product Description and Components

2
DESCRIPTION
1. Power cord
2. Drip loop
3. Residual current device (RCD)
4. Tile cutting blade
5. On/Off switch
6. Rip guide
7. Mitre guide
8. Max ll line
9. Overow drain
10. Water reservoir
11. Rip fence scale
12. Stand
13. Cord retainer
14. Lift handles
15. Blade guard
16. Bevel table
17. Tile saw housing
18. Hex wrench
19. Arbor wrench
20. Screws
21. Blade guard bracket
22. Hex nut
23. Hex bolt
24. Stand legs “A”
25. Stand legs “B”
26. Leg stand bolt(s)
27. Leg stand nut(s)
28. Leg stand brace(s)
29. Support bracket “A”
30. Support bracket “B”
31. Latches
32. Strain relief
33. Washer(s)
34. Lip
35. Rip guide knob
36. Leg assembly “A”
37. Leg assembly “B”
38. Mitre guide scale
39. Mitre guide knob
40. Bevel table leg
41. 22.5° bevel notch
42. 45° bevel notch
43. Arbor
44. Inner ange
45. Outer ange
46. Arbor nut
