10 — English
KNOW YOUR GENERATOR
See Figure 2.
The safe use of this product requires an understanding of the
information on the product and in this operator’s manual as
well as a knowledge of the project you are attempting. Before
use of this product, familiarize yourself with all operating
features and safety rules.
AC CIRCUIT BREAKERS
The circuit breakers are provided to protect the generator
against electrical overload. The circuit breaker may be reset
by pressing the circuit breaker reset button.
AIR FILTER
The air filter helps to limit the amount of dirt and dust drawn
into the unit during operation.
ANSI/UL-2201 CERTIFIED
This generator complies with the ANSI/UL-2201 Standard
for Low Carbon Monoxide (CO) Emission Rates for portable
generators. When used properly, portable generators with
lowered CO emissions and CO shutoff capability mitigate
the risk of CO related poisoning.
DANGER:
ANSI/UL 2201 compliance is not a substitute for safe
generator practices. Always operate the generator in
open, outdoor areas, at least 20 feet away from occu-
pied structures. Never operate the generator near open
windows, doors, or other unventilated spaces.
AUTO IDLE SWITCH
The auto idle switch is used to control the speed of the
engine and conserve fuel. When the switch is in the ON (I)
position and no appliances are connected to the unit, the
engine will idle. If an appliance is added, the engine speed
will increase to power the item. If the appliance is removed,
the engine will return to idle.
DIGITAL DISPLAY
The digital display shows AC voltage output, frequency, how
long the engine has been running during the current usage
period, and the total number of hours the unit has been used.
FUEL VALVE
Fuel flow from the fuel tank to the engine is turned on and
off using the fuel valve.
GROUND TERMINAL
The ground terminal is used to assist in properly grounding
the generator to help protect against electrical shock. Consult
with a qualified local electrician for grounding requirements
in your area.
LOW OIL SHUT DOWN PROTECTOR
The low oil sensor causes the engine to stop if the level of
lubricant in the crankcase is insufficient.
OIL CAP/DIPSTICK
Remove the oil fill cap to check and add lubricant to the
generator when necessary.
OIL DRAIN PLUG
When changing the engine lubricant, unscrew and remove
the oil drain plug to allow old engine lubricant to be drained.
RECEPTACLES
Your generator has the following single phase, 60 Hz outlets:
four 120V 20A AC duplex GFCI protected receptacles, one
120V 30A AC RV receptacle, and one 120V 23A / 240V 23A
AC receptacle. These can be used for operating appropriate
appliances, electrical lighting, tools, and motor loads.
NOTE: Select 240V on the outlet selector to use the 120V
/ 240V AC receptacle. A power adaptor will be needed to
receive 120V from this receptacle. When 240V is selected
on the outlet selector, no power will go to the other 120V
receptacles.
USB-A CHARGING PORT
The USB-A, 1.0 amp charging port can charge small devices
such as mobile phones, tablets, etc.
PRODUCT SPECIFICATIONS
ENGINE
Engine Type
......................................................298cc, OHV
Replacement Spark Plug
.............. LG F7RTC or equivalent
Lubricant Fill Volume
......................... approximately 25 oz.
Fuel Volume
................................................................ 4 gal.
GENERATOR
Rated Voltage
.................................................... 120V/240V
Rated Amps ..................................................... 45.8A/22.9A
Rated Output* ..........................................................5500 W
Starting Watts .......................................................... 6500 W
Rated Frequency ........................................................60 Hz
FEATURES
*Rated output determined by PGMA Standard G300
