RYOBI TILE SAW – MODEL NUMBER WS721
PARTS LIST FOR FIGURE A
Key Part
No. Number Description Qty.
The model number will be found on a plate attached to the housing. Always mention the model number in all correspondence regarding your TILE
SAW or when ordering repair parts.
1 080009019703 Rip Fence Assembly .................................................... 1
2 080009019704 Miter Guage Assembly ................................................ 1
3 411012001 Hex Nut (M5) ............................................................... 4
4 080009019700 Motor Assembly .......................................................... 1
5 080009019030 Washer (D5 x D9 x 0.8t) ............................................... 6
6 412042002 External Tooth Lock Washer (M4) ................................ 2
7 089009019089 Grounding Lead ........................................................... 1
8 080009019904 Data Label ................................................................... 1
9 410132057 Screw (M4 x 8 mm, Pan Hd.) ...................................... 1
10 080009019031 Screw (M5 x 59.5 mm, Pan Hd.) ................................. 4
11 080009019021 Screw (M3 x 8 mm, Pan Hd.) ...................................... 4
12 080009019709 Front Seal Cap w/O-Rings .......................................... 1
13 080009019023 Rubber Gasket ............................................................ 1
14 080009019024 Cover Plate .................................................................. 1
15 080009019026 Washer (D3 x D8.5 x 0.5t) ............................................ 6
16 080009019025 Screw (M3 x 12 mm, Pan Hd.) .................................... 6
17 080009019036 Work Table (Left) .......................................................... 1
18 080009019037 Screw (M5 x 13.5 mm, Pan Hd.) ................................. 4
19 080009019701 Blade Guard Assembly (Inc. Key Nos. 20-23) ............. 1
20 080009019055 Blade Guard Knob ....................................................... 1
21 080009019905 No Hands Warning Label ............................................ 2
22 412042001 External Tooth Lock Washer (M5) ................................ 4
23 080009019057 Screw (M6 x 30 mm, Hex Hd.) .................................... 1
24 080009019059 Screw (M5 x 10 mm, Pan Hd.) .................................... 2
25 080009019054 Riving Knife ................................................................. 1
26 080009019702 Work Table Assembly
(Incl. Key Nos. 27-30, 32, and 65) ............................... 1
27 080009019060 Work Table (Right) ....................................................... 1
28 080009019062 Bevel Plate (Left) ......................................................... 1
29 080009019063 Rotation Plate .............................................................. 2
30 080009019064 Washer (D5.4 x D14 x 1.0t) .......................................... 4
31 451010001 Strain Relief ................................................................. 1
32 080009019061 Bevel Plate (Right) ....................................................... 1
33 080009019706 Overflow Drain Assembly (Inc. Key No. 34) ................. 1
34 080009019011 O-Ring (D24.45 mm x D2.5 mm) ................................. 1
Key Part
No. Number Description Qty.
35 080009019708 Power Cord (Inc. Key No. 36) ...................................... 1
36 080009019903 Danger Label (GFCI) .................................................... 1
37 080009019029 Washer (D4 x D9 x 0.8t) ............................................... 2
38 080009019027 Baffle ........................................................................... 1
39 080009019018 Screw (M4 x 18 mm, Pan Hd.) .................................... 4
40 080009019033 Inner Flange ................................................................. 1
41 080009002061 Cutting Wheel .............................................................. 1
42 080009019034 Outer Flange ................................................................ 1
43 080009019035 Hex Nut (M12 x 1.5 mm) ............................................. 1
44 080009019008 Screw (M3 x 10 mm, Pan Hd.) .................................... 6
45 080009019007 Plate ............................................................................ 1
46 080009019006 Seal (Gasket) ............................................................... 1
47 080009019707 Housing w/Labels (Inc. Key Nos. 48, 52 and 56) .......... 1
48 080009019900 Warning Label (English) ............................................... 1
49 080009019009 Capacitor ..................................................................... 1
50 089110102109 Cord Clamp ................................................................. 1
51 080009019016 Screw (M4 x 14 mm, Pan Hd.) .................................... 2
52 080009019901 Logo Label ................................................................... 1
53 080009019015 Clamping Pad .............................................................. 1
54 080009019014 Screw (M4 x 9.5 mm, Pan Hd.) ................................... 3
55 080009019005 Screw (M3.5 x 25 mm, Pan Hd.) ................................. 2
56 080009019902 Warning Label (French/Spanish) ................................. 1
57 080009019004 Switch Plate ................................................................ 1
58 080009019002 Switch Bezel ................................................................ 1
59 080009019710 Switch Assembly (Inc. Key No. 60) ............................. 1
60 080009019088 Switch Key .................................................................. 1
61 080009019017 Housing Block ............................................................. 1
62 412021005 Spring Washer (M5) ..................................................... 4
63 080009019038 Wrench (A) ................................................................... 1
64 080009019039 Wrench (B) ................................................................... 1
65 080015001427 Lock Nut (M5) .............................................................. 4
Not Shown:
988000052 Operator's Manual ....................................................... 1
9-21-10
(Rev:04)
