7
TECHNICAL SPECIFICATIONS
ENGINE
The two-wheel tractor may be fitted with the following
engines:
− HONDA GC 160; 4 stroke gasoline engine;
3,7 kW (5 CV); 160 cm
3
.
− LOMBARDINI LGA 226; 4 stroke gasoline engine;
4 kW (5,4 CV); 220 cm
3
.
− YANMAR L48; 4 stroke Diesel engine;
4 kW (5,4 CV); 212 cm
3
.
STARTING
Rewind start.
CLUTCH
Cone clutch, oil immersed with control lever.
SPEEDS
MAX SPEED (km/h)
POWER TAKE OFF (PTO)
Mounted attachments are driven via an independent,
single speed PTO engaged by a control lever on the
handlebars.
Maximum PTO speed: 923 rpm (clockwise rotation).
COUPLING OF ATTACHMENTS
Coupling of attachments to the PTO is obtained
through a quick change fitting that provides for fast
installation of the attachments, and does not require
the use of bolts, nuts or spanner.
HANDLEBARS
Adjustable in height and width. Rotate handlebars
through 180 when front-mounted attachments are
used.
WHEELS/TYRES
− Pneumatic tyres with agricultural tread.
− Available sizes: 3.50-6.
− Inflation pressure: 1.2 bar.
NOTE
The instructions covering track adjustment, based on
motor-mower model and type of wheel, are given in a
specific paragraph in this manual
ACCESSORIES
The two-wheel tractor can be fitted with a wide range
of additional easy-to-fit accessories. These are, for in-
stance, several types of iron wheels, watering pumps
and sprayers, snowploughs, ploughs, trailers, water
sprinkling trolleys, etc.
Refer to our catalogue for details about the various
accessories available.
MASS
Refer to the identification plate installed on the ma-
chine.
DIMENSIONS
The overall dimensions of the two-wheel tractor are
shown in fig.2.
