S.R.Smith CYCLONE - Parts List

6
PARTS LIST
Visit srsmith.com for hardware kit and replacement part information.
ITEM NO.
PART NO.
DESCRIPTION
QTY.
KIT A
KIT B
KIT A
69-209-113
CYCLONE HARDWARE KIT
1 ea.
KIT B
69-209-710
CYCLONE WATER KIT
1 ea.
1
5-139
3/8” HEX NUT
2 ea.
●
2
5-151
3/8” LOCK WASHER
2 ea.
●
3
05-14-115
1/2" LOCK WASHER
7 ea.
●
4
5-145
3/8” FLAT WASHER
16 ea.
●
5
5-245
3/8” x 2-1/2” LAG SCREW
10 ea.
●
6
5-240
3/8” x 3-1/2” LAG SCREW
2 ea.
●
7
5-260
3/8” x 6.5” HEX HEAD CAP SCREW
2 ea.
●
8
5-241
1/2"-13 ANCHOR 5" LONG W/NUT & WASHER
7 ea.
●
9
05-711
PVC NIPPLE SCH 80-3/4” x 2”
1 ea.
●
10
05-712
3/4” FHT x 3/4”FIPT SWIVEL 90
1 ea.
●
11
8-531
GASKET
2 ft.
12
5-371
HOSE CLIP SCREW
1 ea.
●
13
05-713
3/4” HOSE CLIP
1 ea.
●
(1)
(5)
(7)
(8)
(3)
(2)
(4)
(10)
(9)
(12)
))
(11)
(6)
(13)
))
