Drive belt
The alternator is situated on the right-hand
side of the engine. It is driven via a poly-V
belt from the crankshaft pulley.
The poly-V-belt also drives the water pump,
the A/C compressor and the steering servo
pump.
The belt tension is critical, and is adjusted
by an automatic belt tensioner.
See also page 61, "Warning charging".
WARNING
• Keep hands and clothing clear of drive
belts when engine is running.
• Always stop the engine before
inspecting drive belts.
• The fan can start even when the
engine is switched off.
NOTE
Serious damage can occur to the car’s
electrical system if an alternator lead is
disconnected while the engine is running.
