Trailer Wiring Harness
Your vehicle is equipped with a seven-wire trailer
towing harness. This harness has a seven-pin universal
heavy-duty trailer connector (if equipped with the
trailering package) that is attached to a bracket on the
hitch platform. If your vehicle is not equipped with the
heavy-duty trailer connector, you can purchase one
from your Saab dealer.
The seven-wire harness contains the following trailer
circuits:
• Yellow: Left Stop/Turn Signal
• Dark Green: Right Stop/Turn Signal
• Brown: Running Lamps
• White: Ground
• Light Green: Back-up Lamps
• Dark Blue: Electric Brakes
• Red: Battery Feed (The chassis wiring ring terminal
must be fastened to a stud on the underhood
electrical center before the trailer feed will become
active.)
If you need to tow a light-duty trailer with a standard
four-way round pin connector, an adapter connector is
available from your dealer.
Your vehicle is also equipped with wiring for an electric
trailer brake controller. These wires are located inside the
vehicle on the driver’s side under the instrument panel.
These wires should be connected to an electric trailer
brake controller by your dealer or a qualified service
center.
4-51
