Saber Compact R50CC0312 - Release Control Panel from Grill Frame

4
For this step, close the Doors on your Grill and raise
the Lid.
This step will require your Gloves.
• Grasp the Control Panel at each end and lift it
straight up from the Grill. You will be disengaging
the three locking tabs that hold the top of the
Control Panel in place.
• Note that there are connections on the rear of the
Control Panel - so do not try to completely remove
the Control Panel yet.
6
Procedure - Removing the Existing Control Panel
Lift only enough to
disengage tabs
Rotate the Control
Panel and allow it to
rest on the top of the
Doors.
Tabs
5
• Using your Phillips Screwdriver, remove the two #8
Sheet Metal Screws from the lower tabs of the
Control Panel.
• Place these Screws in a secure location . They will
be used to install your new Control Panel.
• First - rotate the Control Panel down and let the
bottom of it rest on the Door Handles, as shown.
