62
CRC– ECM / CRT– ECM / CRS– ECM
Accessories for
CRC–ECM / CRT–ECM / CRS–ECM version
40
30
20
10
9
8
7
6
5
4
3
2
1
100 200 300 400 600 800 1000 2000 3000 4000
Kvs 2 Kvs 2,5
Kvs 1,6
Dp - kPa
Water
flow (l/h)
Control valve kit:
3 way valve, ON-OFF,
with electric motor and mounting kit
with micrometric lockshield valve.
VBP
main coil 3 way valve
Control valve kit:
3 way valve, ON-OFF,
with electric motor and mounting kit
with micrometric lockshield valve.
VBA
additional coil 3 way valve
Dimensions ± 10 mm
1 ÷ 7
9
Mod.
1 – 2
3
CRC/CRt CRs
Code
Micrometric lockshield valve Dimensions (mm) Valve
FITTED NOT FITTEDDN (Ø) KvsA B C D DN (Ø) Kvs
9060472H
9060472H
9060475H
9060475H
15
15
1/2” F
1/2” F
2
2
15
15
1/2”
1/2”
1,6
1,6
120
135
195
200
240
235
340
330
1 ÷ 5
6 – 7
9
Mod.
1
2
3
CRC/CRt CRs
Code
Micrometric lockshield valve Dimensions (mm) Valve
FITTED NOT FITTEDDN (Ø) KvsA B C D E DN (Ø) Kvs
9066561H
9060471H
9060471H
9066560H
9060474H
9060474H
15
15
15
1/2” F
1/2” F
1/2” F
2
2
2
15
20
20
1/2”
3/4”
3/4”
1,6
2,5
2,5
25
25
50
85
85
120
190
190
185
290
290
290
105
105
105
Model
VeRsion
MV – Mo – MVB – iV – io
CRC–eCM / CRt–eCM
CRs–eCM
Dimensions ± 10 mm
Model
VeRsion
MV – Mo – MVB – iV – io
CRC–eCM / CRt–eCM
CRs–eCM
