CRC–eCM / CRt–eCM
CRs–eCM
3 way double valve kit for 4 tube installation and single coil
The kit consists of:
• 2 special 3 way valves;
• 2 230 Volt ON-OFF actuators with internal safety micro switch;
• insulated pipe kit;
• external valve insulation sleeve.
The kit uses a special 3 way valve which allows the transformation
of the fan coil, equipped with one single coil, into a 4 tube
installation.
The new 4X2 valve has been designed to keep the water flow
between flow and return perfectly separated, allowing its use
in parallel.
Therefore, it can be used on 4 pipe fan coil systems with one
single heat-exchange coil on board the fan coil.
Cold water
Single coil
Hot water
Double actuator electrical connections
