ENGLISH
22
12.5. SCREEN FORMAT
12.6. MAIN SCREEN
Main screen
Centre
selection button
Left
selection button
Manual operation
Current time
S
:
aM
7
tnu
61
t
4
re
we
Day of the week
Right
selection button
Access to the menu
Power LED
Pump
operational LED
Fault LED
Manual
lights button
12.7. OPERATION MODE
The swimming pool pump’s intelligent controller eliminates electrical panel installation requirements for the pump’s
automatic start-up, the lights, etc. in domestic installations, and includes other functions and protection elements that
a conventional electrical panel does not have.
Its main features are:
-Very intuitive QuickStart assistant for the basic configuration of the unit.
-Timer control activation/deactivation of the swimming pool pump, with three configurable daily cycles and with
the possibility to select the days of the week on which filtration is required.
-Timer control for activating the swimming pool lights, and other programmable timing applications. This function
also enables configuration of the days of the week on which the lights will be activated.
