Saey CROSS - Page 56

56
Loosen the screws for the airbox in the
bottom of the unit,
4 screws M5, SW 3 mm with washers
Remove the pre-cut recess in the bottom plate
for the airbox, if necessary file down the broken
parts
Mount the airbox on the underside of the
the unit, 4 Allen screws M5,
SW 3 mm with washers.
If necessary, a flat seal can be
placed or glued between the airbox
and the bottom of the unit.
Reattach the bottom plate -
2 hexagonal screws on the side
M8, SW 13 mm with washers
Break out the pre-cut cut-out (below) in the
rear wall panel, if necessary file the broken off
parts smooth
Reinstall the rear panel -
6 screws, M6 x 8mm, cross head screws
