Capacity : Bim(64*256), Chinese character(10CCPL * 2 LINE, 8192 *16*16
Chinese character) , character(20CPI * 2LINE , 16*8) ,User-define
content(4*16*16).
1.9.2. LED Indicators
Led indication in on-line
LED ON OFF BLINK
LED1(ON) POWER ON POWER OFF
LED2(READY)
RECEIVING
DATA
LED3(STATION 1)
ASSIGNED TO
USER 1
LED4(STATION 2)
ASSIGNED TO
USER 2
1.9.3. TERMS DEFINITION
ON-LINE: The statue when power on the printer in normal condition (Top
cover is closed and no key is pressed).
STOP MODE: In the on-line mode, pressing STOP▉ key or opening the
cover , the printer will enter STOP MODE.
OFF-LINE OPERATION : In the ON-LINE mode, pressing STATION2 and
COMPRESS▼ keys simultaneously, the printer will enter OFF-LINE
MODE/ OPERATION .
1.9.4. KEYS
The following table shows the keys' function definitions under different states
The following table shows the keys' function definitions under different states
FUNCTION
KEY
ON-LINE STOP MODE OFF-LINE
STATION1
 Assign printer to
user 1, only be
valid under
OLIVETTI
emulation.
 Pressing this key
and power on the
printer, after the
Invalid Invalid
