DRAFT;
N.L.Q.;
L.Q.;
RIBBON BOX Black nylon, indelible
PAPER FEED Front feeder with automatic document
alignment.
PANEL Located on the printer cover, it has 5
buttons, 4 LEDs and 1 LCD.
EMULATIONS OLIVETTI (PR40+, PR9)
IBM (PP II, X24)
IBM 9068/4748
LQ1600K, OKI5330SC/5530SC
INTERFACE Standard RS 232C serial with the
possibility of installing the following
interface cards:
- RS 232C serial + USB
- Centronics parallel
- 2
nd
RS232C serial.
DIMENSIONS Width: 398 mm;
Depth: 296 mm;
Height: 215mm;
Weight: 9.1 Kg (basic model)
ENVIRONMENTAL
CONDITION Temperature:
Operation 5°C ~35°C
Storage / Transport -40 °C ~ 50 °C
Relative Humidity:
Operation 15% ~85%;
Storage / Transport ≤93% (40 °C) .
POWER CONSUMPTION Stand-by: < 15 W;
During operation: 170 W max (worst case).
POWER SUPPLY Voltage:: 200 to 240 VAC ± 10%
Frequency: 50HZ ± 2%.
The following figure gives an overall view of the printer.
