15
Storing Harness System
16
Only store the harness system when converting child
restraint into a booster seat.
To remove accessories, see page 24.
1. Fully Loosen Harness
Straps
Push down on harness release
lever (under fl ap on front of seat
pad) while pulling out on harness
straps as shown.
2. Unbuckle Harness
Press in towards the top of the red
button.
Pull buckle tongues out.
6. Undo Fasteners on
Headrest Pad As Shown
3. Locate Buckle’s Metal
Retainer
Fully recline the child restraint and
reach under the seat between the
base and shell and through the re-
cline handle. Rotate metal retainer
and push it up through shell and
pad.
4. From Top of Seat,
Pull Buckle of Shell and
Pad
Store the buckle in a safe place for
future use.
5. Adjust the Headrest
to the Highest Position
8. Undo Fasteners on Seat
Pad As Shown
7. Pull Headrest Pad Off
Bottom of Headrest
As Shown
continued on next page
