Safety 1st Continuum - Harness System Adjustments for Infants; Using Lower Harness Slots; Reclining Seat and Harness Adjustment

Harness System Adjustments for
Smaller Infants
10
7. Fully Loosen Harness
Straps
Push down on harness release lever
(under fl ap on front of seat pad) while
pulling out on harness straps as shown.
6. Adjust the Headrest to the
Lowest Position
The headrest MUST be in the lowest
position.
8. From Back, Remove Harness
Strap Loops From Splitter
Plate
9. Pull Harness Straps Out of
Upper Shoulder Harness
Slots
continued on next page
9
1. With Buckle in the 1st Slot,
Fully Recline the Seat
If you need to move the buckle to the 1st
slot, see page 6.
5. Replace Pad and Check
Buckle
Pull up on buckle to make sure it is
secured. The buckle MUST not pull
out.
2. Lift Pad Off of Front of
Child Restraint
4. From Top of Seat, Lay the
Metal Retainer Flat Against
the Shell As Shown
3. From Bottom of Seat, Pull
Metal Retainer Down and
Push It Up into Middle Slot
As Shown
When using the lower shoulder harness slots for smaller infants,
you MUST use the body pillow and the headrest MUST be in the
lowest position.
