Saft SBM - Correlation between Block Dimensions and Plate Module Number

9
The block battery uses 4 plate sizes
or plate modules. These are
designated module type 1, 2, 3
and 4. They can be recognized from
the block dimensions as follows:
Block width (mm) Block height (mm) Plate module
123 194 1
123 264 2
195 349 3
195 405 4
Table 1 - Correlation between block dimensions and plate module number
