Saftronics DF8 PLUS Series User Manual

SAFTRONICS
3
••
••
• Rectifier configuration
The DF8 "Plus" employs two single phase, full-wave, fully
controlled, (4 SCR) bridges to allow extremely rapid motor
armature reversing.
••
••
• HP & Current rating
MODEL
HP AMPS
120 VAC 240 VAC INPUT OUTPUT
DF8P-10 1 2 18 10
DF8P-15 1.5 3 25 15
DF8P-25 2.5 5 37 25
••
••
• Voltage rating
INPUT
OUTPUT VDC
ARMATURE FIELD
120 VAC (J6) 90090 100/50
240 VAC (J5) 1800180 200/100
••
••
• Short circuit rating
Suitable for use on a circuit capable of delivering not more than
5000 rms symmetrical amperes, 240 V maximum.
••
••
• Fusing
One fast-acting fuse in each AC leg.
••
••
• Current limit
Adjustable current limit circuit for each bridge.
••
••
• Surge suppression
MOV surge suppressor.
For dimensional information see pages 13 & 14.
2.1 Electrical cont'd
2.3 Mechanical
2.2 Electrical Protection
