7 PARTSLIST RM2042
POSITION DESCRIPTION MANUFACTOR TYPE PART NO.
C83-3 CAPACITOR CERAM. SMD 0805 1n0F 10% X7R 50VDC MURATA GRM40 X7R 102 K 50 PT 328.324
C84-3 CAPACITOR CERAM. SMD 0805 1n0F 10% X7R 50VDC MURATA GRM40 X7R 102 K 50 PT 328.324
C85-3 CAPACITOR CERAM. SMD 0805 1n0F 10% X7R 50VDC MURATA GRM40 X7R 102 K 50 PT 328.324
C86-3 CAPACITOR CERAM. SMD 0805 1n0F 10% X7R 50VDC MURATA GRM40 X7R 102 K 50 PT 328.324
C87-3 CAPACITOR CERAM. SMD 0805 1n0F 10% X7R 50VDC MURATA GRM40 X7R 102 K 50 PT 328.324
C88-3 CAPACITOR CERAM. SMD 0805 1n0F 10% X7R 50VDC MURATA GRM40 X7R 102 K 50 PT 328.324
C89-3 CAPACITOR CERAM. SMD 0805 10pF 5% N150 50VDC MURATA GRM40 P2H 100 D 50 PT 323.474
C90-3 CAPACITOR CERAM. SMD 0805 39pF 5% N150 50VDC MURATA GRM40 P2H 390 J 50 PT 323.481
C91-3 CAPACITOR CERAM. SMD 0805 1n0F 10% X7R 50VDC MURATA GRM40 X7R 102 K 50 PT 328.324
C92-3 CAPACITOR CERAM. SMD 0805 270pF 5% NPO 50VDC TDK C2012 COG 1H 271 J T NiBa 323.091
C93-3 CAPACITOR CERAM. SMD 0805 27pF 5% NPO 50VDC TDK C2012 COG 1H 270 J T NiBa 323.079
C94-3 CAPACITOR CERAM. SMD 0805 270pF 5% NPO 50VDC TDK C2012 COG 1H 271 J T NiBa 323.091
C95-3 CAPACITOR CERAM. SMD 0805 100nF 10% X7R 25VDC MURATA GRM40 X7R 104 K 25 PT 328.348
C96-3 CAPACITOR CERAM. SMD 0805 150pF 5% NPO 50VDC TDK C2012 COG 1H 151 J T NiBa 323.088
C97-3 CAPACITOR CERAM. SMD 1206 1n5 5% NPO 50VDC MURATA GRM42-6COG152J50PT 324.100
C98-3 CAPACITOR CERAM. SMD 0805 100nF 10% X7R 25VDC MURATA GRM40 X7R 104 K 25 PT 328.348
C99-3 CAPACITOR CERAM. SMD 0805 100nF 10% X7R 25VDC MURATA GRM40 X7R 104 K 25 PT 328.348
C100-3 CAPACITOR CERAM. SMD 0805 100nF 10% X7R 25VDC MURATA GRM40 X7R 104 K 25 PT 328.348
C101-3 CAPACITOR CERAM. SMD 1206 3n9F 5% NPO 50VDC MURATA GRM42-6COG392J 50PT 324.105
C102-3 CAPACITOR CERAM. SMD 1206 3n9F 5% NPO 50VDC MURATA GRM42-6COG392J 50PT 324.105
C103-3 CAPACITOR CERAM. SMD 1206 3n9F 5% NPO 50VDC MURATA GRM42-6COG392J 50PT 324.105
C104-3 CAPACITOR CERAM. SMD 1206 3n9F 5% NPO 50VDC MURATA GRM42-6COG392J 50PT 324.105
C105-3 CAPACITOR CERAM. SMD 1206 3n9F 5% NPO 50VDC MURATA GRM42-6COG392J 50PT 324.105
C106-3 CAPACITOR CERAM. SMD 1206 3n9F 5% NPO 50VDC MURATA GRM42-6COG392J 50PT 324.105
C107-3 CAPACITOR CERAM. SMD 1206 3n9F 5% NPO 50VDC MURATA GRM42-6COG392J 50PT 324.105
C108-3 CAPACITOR CERAM. SMD 1206 3n9F 5% NPO 50VDC MURATA GRM42-6COG392J 50PT 324.105
C109-3 CAPACITOR CERAM. SMD 1206 3n9F 5% NPO 50VDC MURATA GRM42-6COG392J 50PT 324.105
C110-3 CAPACITOR CERAM. SMD 1206 3n9F 5% NPO 50VDC MURATA GRM42-6COG392J 50PT 324.105
C111-3 CAPACITOR CERAM. SMD 0805 100nF 10% X7R 25VDC MURATA GRM40 X7R 104 K 25 PT 328.348
C112-3 CAPACITOR CERAM. SMD 0805 100nF 10% X7R 25VDC MURATA GRM40 X7R 104 K 25 PT 328.348
C113-3 CAPACITOR CERAM. SMD 0805 100nF 10% X7R 25VDC MURATA GRM40 X7R 104 K 25 PT 328.348
C114-3 CAPACITOR CERAM. SMD 0805 68pF 5% NPO 50VDC TDK C2012 COG 1H 680 J T NiBa 323.084
C115-3 CAPACITOR CERAM. SMD 0805 330pF 5% NPO 50VDC TDK C2012 COG 1H 331 J T NiBa 323.092
C116-3 CAPACITOR ELECTROLYTIC SM 3u3F 20% 50VDC EUROPE CHEMICON Al-Chip-MKV 50V/3u3 M 333.073
C117-3 CAPACITOR ELECTROLYTIC SM 3u3F 20% 50VDC EUROPE CHEMICON Al-Chip-MKV 50V/3u3 M 333.073
C118-3 CAPACITOR ELECTROLYTIC SM 3u3F 20% 50VDC EUROPE CHEMICON Al-Chip-MKV 50V/3u3 M 333.073
C119-3 CAPACITOR CERAM. SMD 1206 3n9F 5% NPO 50VDC MURATA GRM42-6COG392J 50PT 324.105
C120-3 CAPACITOR ELECTROLYTIC SM 10uF 20% 16VDC EUROPE CHEMICON Al-Chip-MKV 16V/10 M 333.079
C121-3 CAPACITOR CERAM. SMD 0805 1n0F 10% X7R 50VDC MURATA GRM40 X7R 102 K 50 PT 328.324
C122-3 CAPACITOR CERAM. SMD 0805 270pF 5% NPO 50VDC TDK C2012 COG 1H 271 J T NiBa 323.091
C123-3 CAPACITOR CERAM. SMD 0805 27pF 5% NPO 50VDC TDK C2012 COG 1H 270 J T NiBa 323.079
C124-3 CAPACITOR CERAM. SMD 0805 270pF 5% NPO 50VDC TDK C2012 COG 1H 271 J T NiBa 323.091
C125-3 CAPACITOR CERAM. SMD 0805 100nF 10% X7R 25VDC MURATA GRM40 X7R 104 K 25 PT 328.348
C126-3 CAPACITOR CERAM. SMD 0805 150pF 5% NPO 50VDC TDK C2012 COG 1H 151 J T NiBa 323.088
C127-3 CAPACITOR CERAM. SMD 1206 1n5 5% NPO 50VDC MURATA GRM42-6COG152J50PT 324.100
C128-3 CAPACITOR CERAM. SMD 0805 100nF 10% X7R 25VDC MURATA GRM40 X7R 104 K 25 PT 328.348
C129-3 CAPACITOR CERAM. SMD 0805 100nF 10% X7R 25VDC MURATA GRM40 X7R 104 K 25 PT 328.348
C130-3 CAPACITOR CERAM. SMD 0805 100nF 10% X7R 25VDC MURATA GRM40 X7R 104 K 25 PT 328.348
D1-3 DIODE SMALL SIGNAL SOD-80 BAS32L PHILIPS BAS32L 340.032
D2-3 DIODE SMALL SIGNAL SOD-80 BAS32L PHILIPS BAS32L 340.032
D3-3 DIODE DUAL SCHOTTKY BAT54S PHILIPS BAT 54 S 340.310
D4-3 DIODE DUAL SCHOTTKY BAT54S PHILIPS BAT 54 S 340.310
FL1-3 CRYSTAL FILTER Fc=15.3MHz * NDK SP.SPEC: C1076 (15N15B) 40.029
FL2-3 CERAMIC FILTER Fc=450kHz BW=20kHz MURATA SFR450D 41.513
J1-3 ANTENNA JACK (FEMALE) SO239 KAJ V HANSEN SO239 78.504
J2-3 SOCKET 2x8 POLES 1/20" PCB VERSION AMP 4-175639-6 376.006
L1-3 COIL RF 110nH ADJUSTABLE TOKO E526HN-100117 38.409
L2-3 COIL RF 110nH ADJUSTABLE TOKO E526HN-100117 38.409
L3-3 COIL RF 110nH ADJUSTABLE TOKO E526HN-100117 38.409
L4-3 COIL RF 110nH ADJUSTABLE TOKO E526HN-100117 38.409
L5-3 CHOKE FIXED 3u3H 5% COILCRAFT 1008CS-332-XJBC 337.280
L6-3 TRAFO RF 110nH ADJUSTABLE TOKO E526-110436 38.407
L7-3 CHOKE FIXED 120nH 5% COILCRAFT 1008CS-121-XJBC 337.263
L8-3 CHOKE FIXED 1206 68nH 10% COILCRAFT 1206CS-680XKBC 337.110
L9-3 CHOKE FIXED 270nH 5% COILCRAFT 1008CS-271-XJBC 337.267
Q1-3 DUAL GATE MOS-FET N-CHANN BF996S PHILIPS BF996S-215 347.096
Q2-3 TRANSISTOR N-CHAN. JFET TIS88A1 MOTOROLA TM 00 044 -1 29.735
Q3-3 TRANSISTOR N-CHAN. JFET TIS88A1 MOTOROLA TM 00 044 -1 29.735
Q4-3 DUAL GATE MOS-FET N-CHANN BF996S PHILIPS BF996S-215 347.096
Q5-3 TRANSISTOR RF NPN BFR92A PHILIPS BFR92A 345.530
Q6-3 TRANSISTOR RF NPN BFR92A PHILIPS BFR92A 345.530
Q7-3 TRANSISTOR RF NPN BFR92A PHILIPS BFR92A 345.530
R1-3 RESISTOR MF 47k OHM 5% 0.4W PHILIPS 2322 181 53473 01.241
R2-3 RESISTOR SMD 0805 100k OHM 5% 0.1W ROHM MCR 10 EZH J 104 302.072
9716
PAGE 7-8
