7 PARTSLIST RM2042
POSITION DESCRIPTION MANUFACTOR TYPE PART NO.
C6-3 CAPACITOR CERAM. SMD 1206 3p3F +/- 0.25p NPO 500VDC MURATA GRM42-6 COG 3R3 C 500 PT 324.268
C7-3 CAPACITOR CERAM. SMD 0805 6p8F +/-0.25pF N150 50VDC MURATA GRM40 P2H 6R8 C 50 PT 323.472
C8-3 CAPACITOR CERAM. SMD 0805 5p6F +/-0.25pF N150 50VDC MURATA GRM40 P2H 5R6 C 50 PT 323.471
C9-3 CAPACITOR CERAM. SMD 0805 18pF 5% NPO 50VDC TDK C2012 COG 1H 180 J T NiBa 323.077
C10-3 CAPACITOR CERAM. SMD 0805 1n0F 10% X7R 50VDC MURATA GRM40 X7R 102 K 50 PT 328.324
C11-3 CAPACITOR CERAM. SMD 0805 1n0F 10% X7R 50VDC MURATA GRM40 X7R 102 K 50 PT 328.324
C12-3 CAPACITOR CERAM. SMD 0805 1n0F 10% X7R 50VDC MURATA GRM40 X7R 102 K 50 PT 328.324
C13-3 CAPACITOR CERAM. SMD 0805 56pF 5% NPO 50VDC TDK C2012 COG 1H 560 J T NiBa 323.083
C14-3 CAPACITOR CERAM. SMD 0805 1n0F 10% X7R 50VDC MURATA GRM40 X7R 102 K 50 PT 328.324
C15-3 CAPACITOR CERAM. SMD 0805 12pF 5% N150 50VDC MURATA GRM40 P2H 120 J 50 PT 323.475
C16-3 CAPACITOR CERAM. SMD 0805 3p3F +/-0.25pF N150 50VDC MURATA GRM40 P2H 3R3 C 50 PT 323.468
C17-3 CAPACITOR CERAM. SMD 0805 8p2F +/-0.25pF N150 50VDC MURATA GRM40 P2H 8R2 C 50 PT 323.473
C18-3 CAPACITOR CERAM. SMD 0805 8p2F +/-0.25pF N150 50VDC MURATA GRM40 P2H 8R2 C 50 PT 323.473
C19-3 CAPACITOR CERAM. SMD 0805 3p3F +/-0.25pF N150 50VDC MURATA GRM40 P2H 3R3 C 50 PT 323.468
C20-3 CAPACITOR CERAM. SMD 0805 12pF 5% N150 50VDC MURATA GRM40 P2H 120 J 50 PT 323.475
C21-3 CAPACITOR CERAM. SMD 0805 10nF 10% X7R 50VDC MURATA GRM40 X7R 103 K 50 PT 328.336
C22-3 CAPACITOR CERAM. SMD 0805 10nF 10% X7R 50VDC MURATA GRM40 X7R 103 K 50 PT 328.336
C23-3 CAPACITOR CERAM. SMD 0805 56pF 5% NPO 50VDC TDK C2012 COG 1H 560 J T NiBa 323.083
C24-3 CAPACITOR CERAM. SMD 0805 33pF 5% N150 50VDC MURATA GRM40 P2H 330 J 50 PT 323.480
C25-3 CAPACITOR CERAM. SMD 0805 2p7F +/-0.25pF NPO 50VDC MURATA GRM40 COG 2R7 C 50 PT 323.067
C26-3 CAPACITOR CERAM. SMD 0805 10nF 10% X7R 50VDC MURATA GRM40 X7R 103 K 50 PT 328.336
C27-3 CAPACITOR CERAM. SMD 0805 10nF 10% X7R 50VDC MURATA GRM40 X7R 103 K 50 PT 328.336
C28-3 CAPACITOR CERAM. SMD 0805 10nF 10% X7R 50VDC MURATA GRM40 X7R 103 K 50 PT 328.336
C29-3 CAPACITOR CERAM. SMD 0805 10nF 10% X7R 50VDC MURATA GRM40 X7R 103 K 50 PT 328.336
C30-3 CAPACITOR CERAM. SMD 1206 1n0F 10% X7R 500VDC MURATA GRM42-6 X7R 102 K 500 PT 324.688
C31-3 CAPACITOR CERAM. SMD 0805 33pF 5% N150 50VDC MURATA GRM40 P2H 330 J 50 PT 323.480
C32-3 CAPACITOR CERAM. SMD 0805 10nF 10% X7R 50VDC MURATA GRM40 X7R 103 K 50 PT 328.336
C33-3 CAPACITOR CERAM. SMD 0805 270pF 5% NPO 50VDC TDK C2012 COG 1H 271 J T NiBa 323.091
C34-3 CAPACITOR TRIMMER SMD 4-25P MURATA TZB04Z250BA 335.024
C35-3 CAPACITOR CERAM. SMD 0805 56pF 5% NPO 50VDC TDK C2012 COG 1H 560 J T NiBa 323.083
C36-3 CAPACITOR CERAM. SMD 0805 56pF 5% NPO 50VDC TDK C2012 COG 1H 560 J T NiBa 323.083
C37-3 CAPACITOR CERAM. SMD 0805 100nF 10% X7R 25VDC MURATA GRM40 X7R 104 K 25 PT 328.348
C38-3 CAPACITOR CERAM. SMD 0805 100nF 10% X7R 25VDC MURATA GRM40 X7R 104 K 25 PT 328.348
C39-3 CAPACITOR CERAM. SMD 0805 56pF 5% NPO 50VDC TDK C2012 COG 1H 560 J T NiBa 323.083
C40-3 CAPACITOR CERAM. SMD 0805 100nF 10% X7R 25VDC MURATA GRM40 X7R 104 K 25 PT 328.348
C41-3 CAPACITOR ELECTROLYTIC SM 10uF 20% 16VDC EUROPE CHEMICON Al-Chip-MKV 16V/10 M 333.079
C42-3 CAPACITOR CERAM. SMD 0805 100nF 10% X7R 25VDC MURATA GRM40 X7R 104 K 25 PT 328.348
C43-3 CAPACITOR CERAM. SMD 0805 22nF 10% X7R 50VDC MURATA GRM40 X7R 223 K 50 PT 328.340
C44-3 CAPACITOR CERAM. SMD 1206 3n9F 5% NPO 50VDC MURATA GRM42-6COG392J 50PT 324.105
C45-3 CAPACITOR CERAM. SMD 1206 3n9F 5% NPO 50VDC MURATA GRM42-6COG392J 50PT 324.105
C46-3 CAPACITOR CERAM. SMD 0805 10nF 10% X7R 50VDC MURATA GRM40 X7R 103 K 50 PT 328.336
C47-3 CAPACITOR CERAM. SMD 0805 100nF 10% X7R 25VDC MURATA GRM40 X7R 104 K 25 PT 328.348
C48-3 CAPACITOR CERAM. SMD 0805 100nF 10% X7R 25VDC MURATA GRM40 X7R 104 K 25 PT 328.348
C49-3 CAPACITOR CERAM. SMD 0805 100nF 10% X7R 25VDC MURATA GRM40 X7R 104 K 25 PT 328.348
C50-3 CAPACITOR CERAM. SMD 0805 100nF 10% X7R 25VDC MURATA GRM40 X7R 104 K 25 PT 328.348
C51-3 CAPACITOR CERAM. SMD 0805 220pF 5% NPO 50VDC TDK C2012 COG 1H 221 J T NiBa 323.090
C52-3 CAPACITOR ELECTROLYTIC SM 10uF 20% 16VDC EUROPE CHEMICON Al-Chip-MKV 16V/10 M 333.079
C53-3 CAPACITOR ELECTROLYTIC SM 10uF 20% 16VDC EUROPE CHEMICON Al-Chip-MKV 16V/10 M 333.079
C56-3 CAPACITOR CERAM. SMD 0805 100nF 10% X7R 25VDC MURATA GRM40 X7R 104 K 25 PT 328.348
C57-3 CAPACITOR CERAM. SMD 0805 1n0F 10% X7R 50VDC MURATA GRM40 X7R 102 K 50 PT 328.324
C58-3 CAPACITOR ELECTROLYTIC SM 10uF 20% 16VDC EUROPE CHEMICON Al-Chip-MKV 16V/10 M 333.079
C59-3 CAPACITOR CERAM. SMD 1206 3n9F 5% NPO 50VDC MURATA GRM42-6COG392J 50PT 324.105
C60-3 CAPACITOR CERAM. SMD 1206 3n9F 5% NPO 50VDC MURATA GRM42-6COG392J 50PT 324.105
C61-3 CAPACITOR CERAM. SMD 0805 100nF 10% X7R 25VDC MURATA GRM40 X7R 104 K 25 PT 328.348
C62-3 CAPACITOR CERAM. SMD 0805 10nF 10% X7R 50VDC MURATA GRM40 X7R 103 K 50 PT 328.336
C63-3 CAPACITOR CERAM. SMD 0805 330pF 5% NPO 50VDC TDK C2012 COG 1H 331 J T NiBa 323.092
C64-3 CAPACITOR CERAM. SMD 0805 10nF 10% X7R 50VDC MURATA GRM40 X7R 103 K 50 PT 328.336
C65-3 CAPACITOR CERAM. SMD 1206 1n5 5% NPO 50VDC MURATA GRM42-6COG152J50PT 324.100
C66-3 CAPACITOR CERAM. SMD 0805 100nF 10% X7R 25VDC MURATA GRM40 X7R 104 K 25 PT 328.348
C68-3 CAPACITOR CERAM. SMD 0805 100nF 10% X7R 25VDC MURATA GRM40 X7R 104 K 25 PT 328.348
C69-3 CAPACITOR ELECTROLYTIC SM 10uF 20% 16VDC EUROPE CHEMICON Al-Chip-MKV 16V/10 M 333.079
C70-3 CAPACITOR CERAM. SMD 0805 100nF 10% X7R 25VDC MURATA GRM40 X7R 104 K 25 PT 328.348
C71-3 CAPACITOR ELECTROLYTIC SM 3u3F 20% 50VDC EUROPE CHEMICON Al-Chip-MKV 50V/3u3 M 333.073
C72-3 CAPACITOR ELECTROLYTIC SM 10uF 20% 16VDC EUROPE CHEMICON Al-Chip-MKV 16V/10 M 333.079
C73-3 CAPACITOR TANTALUM 3528 2u2F 20% 16VDC ERO CB 225020 M E17 334.028
C74-3 CAPACITOR CERAM. SMD 0805 10nF 10% X7R 50VDC MURATA GRM40 X7R 103 K 50 PT 328.336
C75-3 CAPACITOR CERAM. SMD 0805 p47F +/-0.25pF NPO 50VDC TDK C2012 COG 1H R47 C T NiBa 323.058
C76-3 CAPACITOR CERAM. SMD 0805 p56F +/- 0.25p NPO 50VDC MURATA GRM40 COG R56 C 50 PT 323.059
C77-3 CAPACITOR CERAM. SMD 0805 1n0F 10% X7R 50VDC MURATA GRM40 X7R 102 K 50 PT 328.324
C78-3 CAPACITOR CERAM. SMD 0805 1n0F 10% X7R 50VDC MURATA GRM40 X7R 102 K 50 PT 328.324
C79-3 CAPACITOR CERAM. SMD 0805 1n0F 10% X7R 50VDC MURATA GRM40 X7R 102 K 50 PT 328.324
C80-3 CAPACITOR CERAM. SMD 0805 18pF 5% N150 50VDC MURATA GRM40 P2H 180 J 50 PT 323.477
C81-3 CAPACITOR CERAM. SMD 0805 27pF 5% N150 50VDC MURATA GRM40 P2H 270 J 50 PT 323.479
C82-3 CAPACITOR CERAM. SMD 0805 56pF 5% N150 50VDC MURATA GRM40 P2H 560 J 50 PT 323.483
9716
PAGE 7-7
