7 PARTSLIST RM2042
POSITION DESCRIPTION MANUFACTOR TYPE PART NO.
R19-2 RESISTOR SMD 0805 10k OHM 5% 0.1W ROHM MCR 10 EZH J 103 302.060
R20-2 RESISTOR SMD 0805 10k OHM 5% 0.1W ROHM MCR 10 EZH J 103 302.060
R21-2 RESISTOR SMD 0805 2k2 OHM 5% 0.1W ROHM MCR 10 EZH J 222 302.052
R22-2 RESISTOR SMD 0805 2k2 OHM 5% 0.1W ROHM MCR 10 EZH J 222 302.052
R23-2 RESISTOR SMD 0805 10k OHM 5% 0.1W ROHM MCR 10 EZH J 103 302.060
R24-2 RESISTOR SMD 0805 4k7 OHM 5% 0.1W ROHM MCR 10 EZH J 472 302.056
R25-2 RESISTOR SMD 0805 10k OHM 5% 0.1W ROHM MCR 10 EZH J 103 302.060
R26-2 RESISTOR SMD 0805 100 OHM 5% 0.1W ROHM MCR 10 EZH J 101 302.036
R27-2 RESISTOR SMD 0805 100 OHM 5% 0.1W ROHM MCR 10 EZH J 101 302.036
R28-2 RESISTOR SMD 0805 100 OHM 5% 0.1W ROHM MCR 10 EZH J 101 302.036
R29-2 RESISTOR SMD 0805 100 OHM 5% 0.1W ROHM MCR 10 EZH J 101 302.036
R30-2 RESISTOR SMD 0805 100 OHM 5% 0.1W ROHM MCR 10 EZH J 101 302.036
R31-2 RESISTOR SMD 0805 100 OHM 5% 0.1W ROHM MCR 10 EZH J 101 302.036
R32-2 RESISTOR SMD 0805 100 OHM 5% 0.1W ROHM MCR 10 EZH J 101 302.036
R33-2 RESISTOR SMD 0805 10k OHM 5% 0.1W ROHM MCR 10 EZH J 103 302.060
R34-2 RESISTOR SMD 0805 10k OHM 5% 0.1W ROHM MCR 10 EZH J 103 302.060
R35-2 RESISTOR SMD 0805 100k OHM 5% 0.1W ROHM MCR 10 EZH J 104 302.072
R36-2 RESISTOR SMD 0805 56k OHM 5% 0.1W ROHM MCR 10 EZH J 563 302.069
R37-2 RESISTOR SMD 0805 100k OHM 5% 0.1W ROHM MCR 10 EZH J 104 302.072
R38-2 RESISTOR SMD 0805 1M0 OHM 5% 0.1W ROHM MCR 10 EZH J 105 302.084
R39-2 RESISTOR SMD 0805 100 OHM 5% 0.1W ROHM MCR 10 EZH J 101 302.036
R40-2 RESISTOR SMD 0805 100 OHM 5% 0.1W ROHM MCR 10 EZH J 101 302.036
R41-2 RESISTOR SMD 0805 100 OHM 5% 0.1W ROHM MCR 10 EZH J 101 302.036
S1-2 ROTARY SWITCH SP ON-OFF-ON COPAL CS-4-12YTA 373.100
U1-2 EEPROM 8kx8 Taa<=200nSecs 28C64A, 28C64B CATALYST CAT28C64BN-20 TE7/TE13 356.210
U2-2 SRAM 8kx8 Taa<=150nSecs UM6264BM,MSM5165AL,HM6264 UMC UM 6264BM-10L 356.310
U3-2 PROGRAMMED PROM U3-2 RM2042 (C1123,“ODD“) ECI A/S 0-0-29653 / C1123D-6A3A 729653
U4-2 SRAM 8kx8 Taa<=150nSecs UM6264BM,MSM5165AL,HM6264 UMC UM 6264BM-10L 356.310
U5-2 PROGRAMMED PROM U5-2 RM2042 (C1124,“EVEN“) ECI A/S 0-0-29654 / C1124D-9795 729654
U6-2 INTEGRATED CIRCUIT 68HC000 MOTOROLA MC68HC000FN8 356.000
U7-2 INTEGRATED CIRCUIT 74HC32D TEXAS* #SN74HC32DR 355.217
U8-2 INTEGRATED CIRCUIT 74HC32D TEXAS* #SN74HC32DR 355.217
U9-2 INTEGRATED CIRCUIT 74HC32D TEXAS* #SN74HC32DR 355.217
U10-2 HEX INVERTERS 74HC04 TEXAS SN74HC04D R 355.205
U11-2 INTEGRATED CIRCUIT 74HC21D TEXAS* #SN74HC21DR 355.214
U12-2 QUAD 2-INPUT NAND GATES 74HC00 TEXAS SN74HC00DR(TAPE&REEL) 355.200
U13-2 INTEGRATED CIRCUIT 74HC08D TEXAS* SN74HC08DR(TAPE&REEL) 355.208
U14-2 INTEGRATED CIRCUIT 74HC393D TEXAS* #SN74HC393DR 355.281
U15-2 INTEGRATED CIRCUIT 74HC05D TEXAS* SN74HC05DR(TAPE&REEL) 355.207
U16-2 HEX INVERTERS 74HC04 TEXAS SN74HC04D R 355.205
U17-2 INTEGRATED CIRCUIT 74HC148 SGS-THOMSON* SN74HC148M1 355.237
U18-2 DUAL D-FF SET/RESET MC74HC74, SN74HC74 MOTOROLA MC74HC74D R2 355.223
U19-2 INTEGRATED CIRCUIT 74HC32D TEXAS* #SN74HC32DR 355.217
U20-2 INTEGRATED CIRCUIT 74HC4040 TOSHIBA TC74HC4040AFN 355.307
U21-2 DUAL D-FF SET/RESET MC74HC74, SN74HC74 MOTOROLA MC74HC74D R2 355.223
U22-2 INTEGRATED CIRCUIT 82C55 OKI M82C55A-2V 356.616
U23-2 3 TO 8 LINE DECODER 74HC138 TEXAS SN74HC138D R 355.235
U24-2 INTEGRATED CIRCUIT 74HC154 MOTOROLA* #MC74HC154DWR2 355.239
U25-2 INTEGRATED CIRCUIT 74HC4040 TOSHIBA TC74HC4040AFN 355.307
U26-2 INTEGRATED CIRCUIT 82C51 OKI* MSM82C51A-2JS 356.610
U27-2 INTEGRATED CIRCUIT 82C54 OKI* MSM82C54JS 356.614
U28-2 INTEGRATED CIRCUIT 74HC08D TEXAS* SN74HC08DR(TAPE&REEL) 355.208
U29-2 DUAL D-FF SET/RESET MC74HC74, SN74HC74 MOTOROLA MC74HC74D R2 355.223
U30-2 DUAL D-FF SET/RESET MC74HC74, SN74HC74 MOTOROLA MC74HC74D R2 355.223
U31-2 INTEGRATED CIRCUIT DP8573A NATIONAL* DP8573AV 356.630
U32-2 INTEGRATED CIRCUIT LTC1044 LINEAR TECHNOLO LTC1044AIS8 350.010
U33-2 DUAL D-FF SET/RESET MC74HC74, SN74HC74 MOTOROLA MC74HC74D R2 355.223
U34-2 INTEGRATED CIRCUIT 74HC08D TEXAS* SN74HC08DR(TAPE&REEL) 355.208
X1-2 CRYSTAL 8.000MHz HC-49/U NDK LN-P-0002 8.000MHz 39.771
X2-2 CRYSTAL 4.9152 MHz HC-49/U NDK LN-P-00014.9152MHz 39.769
X3-2 CRYSTAL 32.768kHz NDK MU-206S 39.765
RECEIVER (MODULE 3) RM204 RM2042 ECI A/S 5-0-26943E / 4-0-26943J 626943
POSITION DESCRIPTION MANUFACTOR TYPE PART NO.
C1-3 CAPACITOR CERAM. SMD 1206 1n0F 10% X7R 500VDC MURATA GRM42-6 X7R 102 K 500 PT 324.688
C2-3 CAPACITOR CERAM. SMD 0805 2p7F +/-0.25pF NPO 50VDC MURATA GRM40 COG 2R7 C 50 PT 323.067
C3-3 CAPACITOR CERAM. SMD 0805 1p0F +/-0.25pF NP0 50VDC TDK C2012 COG 1H 010 C T NiBa 323.062
C4-3 CAPACITOR CERAM. SMD 1206 1n0F 10% X7R 500VDC MURATA GRM42-6 X7R 102 K 500 PT 324.688
C5-3 CAPACITOR CERAM. SMD 1206 2p2F +/- 0.25p NPO 500VDC MURATA GRM42-6 COG 2R2 C 500 PT 324.266
9716
PAGE 7-6
