Sailor RM2042 - Page 99

7 PARTSLIST RM2042
POSITION DESCRIPTION MANUFACTOR TYPE PART NO.
C37-2 CAPACITOR CERAM. SMD 0805 100nF 10% X7R 25VDC MURATA GRM40 X7R 104 K 25 PT 328.348
C38-2 CAPACITOR CERAM. SMD 0805 47pF 5% NPO 50VDC TDK C2012 COG 1H 470 J T NiBa 323.082
C39-2 CAPACITOR TRIMMER SMD 4-25P MURATA TZB04Z250BA 335.024
C40-2 CAPACITOR CERAM. SMD 0805 100nF 10% X7R 25VDC MURATA GRM40 X7R 104 K 25 PT 328.348
C41-2 CAPACITOR ELECTROLYTIC SM 10uF 20% 16VDC EUROPE CHEMICON Al-Chip-MKV 16V/10 M 333.079
C42-2 CAPACITOR ELECTROLYTIC SM 10uF 20% 16VDC EUROPE CHEMICON Al-Chip-MKV 16V/10 M 333.079
C43-2 CAPACITOR CERAM. SMD 0805 100nF 10% X7R 25VDC MURATA GRM40 X7R 104 K 25 PT 328.348
C44-2 CAPACITOR CERAM. SMD 0805 100nF 10% X7R 25VDC MURATA GRM40 X7R 104 K 25 PT 328.348
C45-2 CAPACITOR TRIMMER SMD 4-25P MURATA TZB04Z250BA 335.024
C46-2 CAPACITOR ELECTROLYTIC SM 10uF 20% 16VDC EUROPE CHEMICON Al-Chip-MKV 16V/10 M 333.079
C47-2 CAPACITOR CERAM. SMD 0805 100nF 10% X7R 25VDC MURATA GRM40 X7R 104 K 25 PT 328.348
C48-2 CAPACITOR CERAM. SMD 0805 100nF 10% X7R 25VDC MURATA GRM40 X7R 104 K 25 PT 328.348
C49-2 CAPACITOR CERAM. SMD 0805 1n0F 10% X7R 50VDC MURATA GRM40 X7R 102 K 50 PT 328.324
C50-2 CAPACITOR CERAM. SMD 0805 1n0F 10% X7R 50VDC MURATA GRM40 X7R 102 K 50 PT 328.324
C51-2 CAPACITOR CERAM. SMD 0805 1n0F 10% X7R 50VDC MURATA GRM40 X7R 102 K 50 PT 328.324
C52-2 CAPACITOR CERAM. SMD 0805 1n0F 10% X7R 50VDC MURATA GRM40 X7R 102 K 50 PT 328.324
C53-2 CAPACITOR CERAM. SMD 0805 1n0F 10% X7R 50VDC MURATA GRM40 X7R 102 K 50 PT 328.324
C54-2 CAPACITOR CERAM. SMD 0805 1n0F 10% X7R 50VDC MURATA GRM40 X7R 102 K 50 PT 328.324
C55-2 CAPACITOR CERAM. SMD 0805 1n0F 10% X7R 50VDC MURATA GRM40 X7R 102 K 50 PT 328.324
D1-2 DIODE SMALL SIGNAL SOD-80 BAS32L PHILIPS BAS32L 340.032
D2-2 DIODE SMALL SIGNAL SOD-80 BAS32L PHILIPS BAS32L 340.032
FP1-2 EMI FERRITE BEAD 3.2x1.6x1.6mm 0.2A MURATA BLM 31 B 601 S PT 370.021
FP2-2 EMI FERRITE BEAD 3.2x1.6x1.6mm 0.2A MURATA BLM 31 B 601 S PT 370.021
FP3-2 EMI FERRITE BEAD 3.2x1.6x1.6mm 0.2A MURATA BLM 31 B 601 S PT 370.021
FP4-2 EMI FERRITE BEAD 3.2x1.6x1.6mm 0.2A MURATA BLM 31 B 601 S PT 370.021
FP5-2 EMI FERRITE BEAD 3.2x1.6x1.6mm 0.2A MURATA BLM 31 B 601 S PT 370.021
FP6-2 EMI FERRITE BEAD 3.2x1.6x1.6mm 0.2A MURATA BLM 31 B 601 S PT 370.021
FP7-2 EMI FERRITE BEAD 3.2x1.6x1.6mm 0.2A MURATA BLM 31 B 601 S PT 370.021
FP8-2 EMI FERRITE BEAD 3.2x1.6x1.6mm 0.2A MURATA BLM 31 B 601 S PT 370.021
FP9-2 EMI FERRITE BEAD 3.2x1.6x1.6mm 0.2A MURATA BLM 31 B 601 S PT 370.021
FP10-2 EMI FERRITE BEAD 3.2x1.6x1.6mm 0.2A MURATA BLM 31 B 601 S PT 370.021
FP11-2 EMI FERRITE BEAD 3.2x1.6x1.6mm 0.2A MURATA BLM 31 B 601 S PT 370.021
FP12-2 EMI FERRITE BEAD 3.2x1.6x1.6mm 0.2A MURATA BLM 31 B 601 S PT 370.021
FP13-2 EMI FERRITE BEAD 3.2x1.6x1.6mm 0.2A MURATA BLM 31 B 601 S PT 370.021
FP14-2 EMI FERRITE BEAD 3.2x1.6x1.6mm 0.2A MURATA BLM 31 B 601 S PT 370.021
FP15-2 EMI FERRITE BEAD 3.2x1.6x1.6mm 0.2A MURATA BLM 31 B 601 S PT 370.021
FP16-2 EMI FERRITE BEAD 3.2x1.6x1.6mm 0.2A MURATA BLM 31 B 601 S PT 370.021
FP17-2 EMI FERRITE BEAD 3.2x1.6x1.6mm 0.2A MURATA BLM 31 B 601 S PT 370.021
FP18-2 EMI FERRITE BEAD 3.2x1.6x1.6mm 0.2A MURATA BLM 31 B 601 S PT 370.021
FP19-2 EMI FERRITE BEAD 3.2x1.6x1.6mm 0.2A MURATA BLM 31 B 601 S PT 370.021
FP20-2 EMI FERRITE BEAD 3.2x1.6x1.6mm 0.2A MURATA BLM 31 B 601 S PT 370.021
FP21-2 EMI FERRITE BEAD 3.2x1.6x1.6mm 0.2A MURATA BLM 31 B 601 S PT 370.021
FP22-2 EMI FERRITE BEAD 3.2x1.6x1.6mm 0.2A MURATA BLM 31 B 601 S PT 370.021
FP23-2 EMI FERRITE BEAD 3.2x1.6x1.6mm 0.2A MURATA BLM 31 B 601 S PT 370.021
FP24-2 EMI FERRITE BEAD 3.2x1.6x1.6mm 0.2A MURATA BLM 31 B 601 S PT 370.021
J1-2 SOCKET 2x8 POLES 1/20" PCB VERSION AMP 4-175639-6 376.006
J2-2 SOCKET 2x7 POLES PCB VERSION AMP 1-215079-4 78.196
J3-2 SOCKET 2x8 POLES 1/20" PCB VERSION AMP 4-175639-6 376.006
J4-2 SOCKET PCB VERSION 2x10 POLES u-MATCH AMP 2-215079-0 / 9-215079-0 78.198
J5-2 SOCKET 2x8 POLES 1/20" PCB VERSION AMP 4-175639-6 376.006
J6-2 SOCKET 2x8 POLES 1/20" PCB VERSION AMP 4-175639-6 376.006
L1-2 CHOKE FIXED 1u0H 10% SIEMENS B78108-T1102-K 20.347
Q1-2 TRANSISTOR AF NPN BC848B MOTOROLA BC848BLT1 (T3) 345.048
Q2-2 TRANSISTOR AF NPN BC848B MOTOROLA BC848BLT1 (T3) 345.048
Q3-2 TRANSISTOR AF SMALL SIGN SOT23 BC858B MOTOROLA BC858BT1 (T3) 345.058
Q4-2 TRANSISTOR AF NPN BC848B MOTOROLA BC848BLT1 (T3) 345.048
R1-2 RESISTOR SMD 0805 10k OHM 5% 0.1W ROHM MCR 10 EZH J 103 302.060
R2-2 RESISTOR SMD 0805 10k OHM 5% 0.1W ROHM MCR 10 EZH J 103 302.060
R3-2 RESISTOR SMD 0805 270k OHM 5% 0.1W ROHM MCR 10 EZH J 274 302.077
R4-2 RESISTOR SMD 0805 1M0 OHM 5% 0.1W ROHM MCR 10 EZH J 105 302.084
R5-2 RESISTOR SMD 0805 1M0 OHM 5% 0.1W ROHM MCR 10 EZH J 105 302.084
R6-2 RESISTOR SMD 0805 4k7 OHM 5% 0.1W ROHM MCR 10 EZH J 472 302.056
R7-2 RESISTOR SMD 0805 4k7 OHM 5% 0.1W ROHM MCR 10 EZH J 472 302.056
R8-2 RESISTOR SMD 0805 4k7 OHM 5% 0.1W ROHM MCR 10 EZH J 472 302.056
R9-2 RESISTOR SMD 0805 4k7 OHM 5% 0.1W ROHM MCR 10 EZH J 472 302.056
R10-2 RESISTOR SMD 0805 4k7 OHM 5% 0.1W ROHM MCR 10 EZH J 472 302.056
R11-2 RESISTOR SMD 0805 56k OHM 5% 0.1W ROHM MCR 10 EZH J 563 302.069
R12-2 RESISTOR SMD 0805 100k OHM 5% 0.1W ROHM MCR 10 EZH J 104 302.072
R13-2 RESISTOR SMD 0805 10k OHM 5% 0.1W ROHM MCR 10 EZH J 103 302.060
R14-2 RESISTOR SMD 0805 56k OHM 5% 0.1W ROHM MCR 10 EZH J 563 302.069
R15-2 RESISTOR SMD 0805 100k OHM 5% 0.1W ROHM MCR 10 EZH J 104 302.072
R16-2 RESISTOR SMD 0805 10k OHM 5% 0.1W ROHM MCR 10 EZH J 103 302.060
R17-2 RESISTOR SMD 0805 4k7 OHM 5% 0.1W ROHM MCR 10 EZH J 472 302.056
R18-2 RESISTOR SMD 0805 4k7 OHM 5% 0.1W ROHM MCR 10 EZH J 472 302.056
9716
PAGE 7-5
