Sailor RM2042 - RM2042 Microprocessor Module 2 Parts List

7 PARTSLIST RM2042
POSITION DESCRIPTION MANUFACTOR TYPE PART NO.
INTERFACE MODULE 1 RM2042 ECI A/S 5-0-26941F / 4-0-26941K 62694101
POSITION DESCRIPTION MANUFACTOR TYPE PART NO.
C66-1 CAPACITOR CERAM. SMD 0805 100nF 10% X7R 25VDC MURATA GRM40 X7R 104 K 25 PT 328.348
C67-1 CAPACITOR CERAM. SMD 0805 100nF 10% X7R 25VDC MURATA GRM40 X7R 104 K 25 PT 328.348
C68-1 CAPACITOR CERAM. SMD 0805 100nF 10% X7R 25VDC MURATA GRM40 X7R 104 K 25 PT 328.348
R79-1 RESISTOR SMD 0805 1k0 OHM 5% 0.1W ROHM MCR 10 EZH J 102 302.048
R80-1 RESISTOR SMD 0805 10k OHM 5% 0.1W ROHM MCR 10 EZH J 103 302.060
R81-1 RESISTOR SMD 0805 1k0 OHM 5% 0.1W ROHM MCR 10 EZH J 102 302.048
R82-1 RESISTOR SMD 0805 1k0 OHM 5% 0.1W ROHM MCR 10 EZH J 102 302.048
R83-1 RESISTOR SMD 0805 1k0 OHM 5% 0.1W ROHM MCR 10 EZH J 102 302.048
R84-1 RESISTOR SMD 0805 1k0 OHM 5% 0.1W ROHM MCR 10 EZH J 102 302.048
R85-1 RESISTOR SMD 0805 10k0 OHM 1% 50mW PHILIPS 2322 734 2/61003 302.470
R86-1 RESISTOR SMD 0805 10k0 OHM 1% 50mW PHILIPS 2322 734 2/61003 302.470
R87-1 RESISTOR SMD 0805 1k0 OHM 5% 0.1W ROHM MCR 10 EZH J 102 302.048
R88-1 RESISTOR SMD 0805 1k0 OHM 5% 0.1W ROHM MCR 10 EZH J 102 302.048
R89-1 RESISTOR SMD 0805 1k0 OHM 5% 0.1W ROHM MCR 10 EZH J 102 302.048
R90-1 RESISTOR SMD 0805 1k0 OHM 5% 0.1W ROHM MCR 10 EZH J 102 302.048
R91-1 RESISTOR SMD 0805 120 OHM 5% 0.1W ROHM MCR 10 EZH J 121 302.037
R92-1 RESISTOR SMD 0805 120 OHM 5% 0.1W ROHM MCR 10 EZH J 121 302.037
R93-1 RESISTOR SMD 0805 1k0 OHM 5% 0.1W ROHM MCR 10 EZH J 102 302.048
R94-1 RESISTOR SMD 0805 100 OHM 5% 0.1W ROHM MCR 10 EZH J 101 302.036
R95-1 RESISTOR SMD 0805 100 OHM 5% 0.1W ROHM MCR 10 EZH J 101 302.036
U13-1 QUAD 8BIT ADC PARALLEL AD7824 ANALOG DEVICES AD7824KR 351.854
U14-1 DUAL 8BIT DAC PARALLEL AD7302 ANALOG DEVICES AD7302BR 351.806
U15-1 WATCH DOG 5V INCL. TIMER MAXIM MAX705CSA REEL 356.642
U16-1 RS485 DUPLEX TRANCEIVER MAX488 MAXIM MAX488 CSA (ESA) 356.607
U17-1 INTEGRATED CIRCUIT 74HC32D TEXAS* #SN74HC32DR 355.217
MICROPROCESSOR (MODULE 2) RM2042 ECI A/S 5-0-26942L / 4-0-26942M 626942
POSITION DESCRIPTION MANUFACTOR TYPE PART NO.
B1-2 BATTERY LITHIUM 3V 0.17Ah •12x11.5mm SANYO CR-1/3N-FT1 47.004
C1-2 CAPACITOR CERAM. SMD 0805 100nF 10% X7R 25VDC MURATA GRM40 X7R 104 K 25 PT 328.348
C2-2 CAPACITOR CERAM. SMD 0805 100nF 10% X7R 25VDC MURATA GRM40 X7R 104 K 25 PT 328.348
C3-2 CAPACITOR CERAM. SMD 0805 100nF 10% X7R 25VDC MURATA GRM40 X7R 104 K 25 PT 328.348
C4-2 CAPACITOR CERAM. SMD 0805 100nF 10% X7R 25VDC MURATA GRM40 X7R 104 K 25 PT 328.348
C5-2 CAPACITOR CERAM. SMD 0805 100nF 10% X7R 25VDC MURATA GRM40 X7R 104 K 25 PT 328.348
C6-2 CAPACITOR CERAM. SMD 0805 100nF 10% X7R 25VDC MURATA GRM40 X7R 104 K 25 PT 328.348
C7-2 CAPACITOR CERAM. SMD 0805 100nF 10% X7R 25VDC MURATA GRM40 X7R 104 K 25 PT 328.348
C8-2 CAPACITOR CERAM. SMD 0805 100nF 10% X7R 25VDC MURATA GRM40 X7R 104 K 25 PT 328.348
C9-2 CAPACITOR CERAM. SMD 0805 100nF 10% X7R 25VDC MURATA GRM40 X7R 104 K 25 PT 328.348
C10-2 CAPACITOR CERAM. SMD 0805 100nF 10% X7R 25VDC MURATA GRM40 X7R 104 K 25 PT 328.348
C11-2 CAPACITOR CERAM. SMD 0805 100nF 10% X7R 25VDC MURATA GRM40 X7R 104 K 25 PT 328.348
C12-2 CAPACITOR CERAM. SMD 0805 100nF 10% X7R 25VDC MURATA GRM40 X7R 104 K 25 PT 328.348
C13-2 CAPACITOR CERAM. SMD 0805 100nF 10% X7R 25VDC MURATA GRM40 X7R 104 K 25 PT 328.348
C14-2 CAPACITOR TANTALUM 3216 1u5F 20% 16VDC ERO C A 155016 M E17 334.007
C15-2 CAPACITOR CERAM. SMD 0805 100nF 10% X7R 25VDC MURATA GRM40 X7R 104 K 25 PT 328.348
C16-2 CAPACITOR CERAM. SMD 0805 100nF 10% X7R 25VDC MURATA GRM40 X7R 104 K 25 PT 328.348
C17-2 CAPACITOR CERAM. SMD 0805 33pF 5% NPO 50VDC TDK C2 012 COG 1H 330 J T NiBa 323.080
C18-2 CAPACITOR CERAM. SMD 0805 33pF 5% NPO 50VDC TDK C2 012 COG 1H 330 J T NiBa 323.080
C19-2 CAPACITOR CERAM. SMD 0805 33pF 5% NPO 50VDC TDK C2 012 COG 1H 330 J T NiBa 323.080
C20-2 CAPACITOR CERAM. SMD 0805 10pF 5% NPO 50VDC TDK C2012 COG 1H 100 D T NiBa 323.074
C21-2 CAPACITOR CERAM. SMD 0805 100nF 10% X7R 25VDC MURATA GRM40 X7R 104 K 25 PT 328.348
C23-2 CAPACITOR CERAM. SMD 0805 100nF 10% X7R 25VDC MURATA GRM40 X7R 104 K 25 PT 328.348
C24-2 CAPACITOR CERAM. SMD 0805 100nF 10% X7R 25VDC MURATA GRM40 X7R 104 K 25 PT 328.348
C25-2 CAPACITOR CERAM. SMD 0805 100nF 10% X7R 25VDC MURATA GRM40 X7R 104 K 25 PT 328.348
C26-2 CAPACITOR CERAM. SMD 0805 100nF 10% X7R 25VDC MURATA GRM40 X7R 104 K 25 PT 328.348
C27-2 CAPACITOR CERAM. SMD 0805 100nF 10% X7R 25VDC MURATA GRM40 X7R 104 K 25 PT 328.348
C28-2 CAPACITOR CERAM. SMD 0805 100nF 10% X7R 25VDC MURATA GRM40 X7R 104 K 25 PT 328.348
C29-2 CAPACITOR CERAM. SMD 0805 100nF 10% X7R 25VDC MURATA GRM40 X7R 104 K 25 PT 328.348
C30-2 CAPACITOR CERAM. SMD 0805 100nF 10% X7R 25VDC MURATA GRM40 X7R 104 K 25 PT 328.348
C31-2 CAPACITOR CERAM. SMD 0805 100nF 10% X7R 25VDC MURATA GRM40 X7R 104 K 25 PT 328.348
C32-2 CAPACITOR CERAM. SMD 0805 100nF 10% X7R 25VDC MURATA GRM40 X7R 104 K 25 PT 328.348
C33-2 CAPACITOR CERAM. SMD 0805 100nF 10% X7R 25VDC MURATA GRM40 X7R 104 K 25 PT 328.348
C34-2 CAPACITOR CERAM. SMD 0805 100nF 10% X7R 25VDC MURATA GRM40 X7R 104 K 25 PT 328.348
C35-2 CAPACITOR CERAM. SMD 0805 100nF 10% X7R 25VDC MURATA GRM40 X7R 104 K 25 PT 328.348
C36-2 CAPACITOR CERAM. SMD 0805 100nF 10% X7R 25VDC MURATA GRM40 X7R 104 K 25 PT 328.348
9716
PAGE 7-4
