7 PARTSLIST RM2042
POSITION DESCRIPTION MANUFACTOR TYPE PART NO.
R16-1 RESISTOR SMD 0805 2k2 OHM 5% 0.1W ROHM MCR 10 EZH J 222 302.052
R17-1 PRESET SEALED 100k OHM 20% 1/4W BOURNS 3314J-1-104-E(G) 310.412
R18-1 RESISTOR SMD 0805 47k OHM 5% 0.1W ROHM MCR 10 EZH J 473 302.068
R19-1 RESISTOR SMD 0805 2k2 OHM 5% 0.1W ROHM MCR 10 EZH J 222 302.052
R20-1 RESISTOR SMD 0805 27 OHM 5% 0.1W ROHM MCR 10 EZH J 27R 302.029
R21-1 RESISTOR SMD 0805 1k0 OHM 5% 0.1W ROHM MCR 10 EZH J 102 302.048
R22-1 PRESET SEALED 100k OHM 20% 1/4W BOURNS 3314J-1-104-E(G) 310.412
R23-1 RESISTOR SMD 0805 2k7 OHM 5% 0.1W ROHM MCR 10 EZH J 272 302.053
R24-1 RESISTOR SMD 0805 100k OHM 5% 0.1W ROHM MCR 10 EZH J 104 302.072
R25-1 RESISTOR SMD 0805 100k OHM 5% 0.1W ROHM MCR 10 EZH J 104 302.072
R26-1 RESISTOR SMD 0805 1k0 OHM 5% 0.1W ROHM MCR 10 EZH J 102 302.048
R27-1 RESISTOR SMD 0805 27 OHM 5% 0.1W ROHM MCR 10 EZH J 27R 302.029
R28-1 RESISTOR SMD 0805 205k OHM 1% 50mW PHILIPS 2322 734 2/62054 302.600
R29-1 RESISTOR SMD 0805 2k2 OHM 5% 0.1W ROHM MCR 10 EZH J 222 302.052
R30-1 RESISTOR SMD 0805 10k OHM 5% 0.1W ROHM MCR 10 EZH J 103 302.060
R38-1 RESISTOR SMD 0805 100k OHM 5% 0.1W ROHM MCR 10 EZH J 104 302.072
R39-1 RESISTOR SMD 0805 10k OHM 5% 0.1W ROHM MCR 10 EZH J 103 302.060
R40-1 RESISTOR SMD 0805 120k OHM 5% 0.1W ROHM MCR 10 EZH J 124 302.073
R41-1 RESISTOR SMD 0805 330 OHM 5% 0.1W ROHM MCR 10 EZH J 331 302.042
R42-1 RESISTOR SMD 0805 330 OHM 5% 0.1W ROHM MCR 10 EZH J 331 302.042
R43-1 RESISTOR SMD 0805 2k7 OHM 5% 0.1W ROHM MCR 10 EZH J 272 302.053
R44-1 RESISTOR SMD 0805 100k OHM 5% 0.1W ROHM MCR 10 EZH J 104 302.072
R45-1 RESISTOR SMD 0805 3k9 OHM 5% 0.1W ROHM MCR 10 EZH J 392 302.055
R46-1 RESISTOR SMD 0805 47 OHM 5% 0.1W ROHM MCR 10 EZH J 47R 302.032
R47-1 RESISTOR SMD 0805 10k OHM 5% 0.1W ROHM MCR 10 EZH J 103 302.060
R48-1 RESISTOR SMD 0805 10k OHM 5% 0.1W ROHM MCR 10 EZH J 103 302.060
R49-1 RESISTOR SMD 0805 10k OHM 5% 0.1W ROHM MCR 10 EZH J 103 302.060
R50-1 RESISTOR SMD 0805 10k OHM 5% 0.1W ROHM MCR 10 EZH J 103 302.060
R51-1 RESISTOR SMD 0805 1k0 OHM 5% 0.1W ROHM MCR 10 EZH J 102 302.048
R52-1 RESISTOR SMD 0805 4k7 OHM 5% 0.1W ROHM MCR 10 EZH J 472 302.056
R53-1 RESISTOR SMD 0805 4k7 OHM 5% 0.1W ROHM MCR 10 EZH J 472 302.056
R54-1 RESISTOR SMD 0805 4k7 OHM 5% 0.1W ROHM MCR 10 EZH J 472 302.056
R55-1 RESISTOR SMD 0805 4k7 OHM 5% 0.1W ROHM MCR 10 EZH J 472 302.056
R56-1 RESISTOR SMD 0805 4k7 OHM 5% 0.1W ROHM MCR 10 EZH J 472 302.056
R57-1 RESISTOR SMD 0805 4k7 OHM 5% 0.1W ROHM MCR 10 EZH J 472 302.056
R58-1 RESISTOR SMD 0805 100k OHM 5% 0.1W ROHM MCR 10 EZH J 104 302.072
R59-1 RESISTOR SMD 0805 100 OHM 5% 0.1W ROHM MCR 10 EZH J 101 302.036
R60-1 RESISTOR SMD 0805 47k OHM 5% 0.1W ROHM MCR 10 EZH J 473 302.068
R61-1 RESISTOR SMD 0805 47k OHM 5% 0.1W ROHM MCR 10 EZH J 473 302.068
R62-1 RESISTOR SMD 0805 1k0 OHM 5% 0.1W ROHM MCR 10 EZH J 102 302.048
R63-1 RESISTOR SMD 0805 10k OHM 5% 0.1W ROHM MCR 10 EZH J 103 302.060
R64-1 RESISTOR SMD 0805 3k9 OHM 5% 0.1W ROHM MCR 10 EZH J 392 302.055
R65-1 RESISTOR SMD 0805 100k OHM 5% 0.1W ROHM MCR 10 EZH J 104 302.072
R66-1 RESISTOR SMD 0805 390 OHM 5% 0.1W ROHM MCR 10 EZH J 391 302.043
R67-1 RESISTOR SMD 0805 100k OHM 5% 0.1W ROHM MCR 10 EZH J 104 302.072
R68-1 RESISTOR SMD 0805 100k OHM 5% 0.1W ROHM MCR 10 EZH J 104 302.072
R69-1 RESISTOR SMD 0805 10k OHM 5% 0.1W ROHM MCR 10 EZH J 103 302.060
R70-1 RESISTOR SMD 0805 10k OHM 5% 0.1W ROHM MCR 10 EZH J 103 302.060
R71-1 RESISTOR SMD 0805 10k OHM 5% 0.1W ROHM MCR 10 EZH J 103 302.060
R72-1 RESISTOR SMD 0805 10k OHM 5% 0.1W ROHM MCR 10 EZH J 103 302.060
R73-1 RESISTOR SMD 0805 10k OHM 5% 0.1W ROHM MCR 10 EZH J 103 302.060
R74-1 RESISTOR SMD 0805 1k0 OHM 5% 0.1W ROHM MCR 10 EZH J 102 302.048
R75-1 RESISTOR SMD 0805 100k OHM 1% 50mW PHILIPS 2322 734 2/61004 302.570
R76-1 RESISTOR SMD 0805 205k OHM 1% 50mW PHILIPS 2322 734 2/62054 302.600
R77-1 RESISTOR SMD 0805 100k OHM 1% 50mW PHILIPS 2322 734 2/61004 302.570
RE1-1 RELAY DPDT 12VDC/1ADC MEISEI P-12 21.074
S1-1 SWITCH CS-4-22YTA COPAL* CS-4-22YTA 373.102
S2-1 ROTARY SWITCH SP ON-OFF-ON COPAL CS-4-12YTA 373.100
TR1-1 TRAFO AF 1:1 600 OHMS SCANELECTRIC 714.065.79.1 22.502
U1-1 POS. VOLTAGE REG. 5V/1A MC7805, LM340T-5.0 MOTOROLA MC7805CT (MC7805BT) 31.250
U2-1 QUAD COMPARATOR LOW POW. SO14, LM339 LM239 TEXAS LM339DR (LM239DR) 350.540
U3-1 QUAD OP.AMP. LM324 MOTOROLA LM324D R2 350.530
U4-1 AF POWER AMPLIFIER DIL 8 1W BTL. PHILIPS TDA7052 31.432
U5-1 VOLTAGE REGULATOR 5V/0.5A MOTOTOLA MC78M05CDTRK 350.125
U7-1 INTEGRATED CIRCUIT 82C51 OKI* MSM82C51A-2JS 356.610
U8-1 INTEGRATED CIRCUIT 82C51 OKI* MSM82C51A-2JS 356.610
U9-1 INTEGRATED CIRCUIT 82C51 OKI* MSM82C51A-2JS 356.610
U10-1 INTEGRATED CIRCUIT 82C55 OKI M82C55A-2V 356.616
U11-1 RS 232 DRIVER/RECEIVER AD232/MAX232/DS14C232C NATIONAL DS 14C232CWMX 356.605
U12-1 VOLTAGE REGULATOR 5V/0.1A 78L05A MOTOROLA MC78L05ACD R2 350.100
W1-1 SHUNT CONNECTOR FEMALE 2 POLES AMP 142270-1 78.325
W2-1 SHUNT CONNECTOR FEMALE 2 POLES AMP 142270-1 78.325
W3-1 SHUNT CONNECTOR FEMALE 2 POLES AMP 142270-1 78.325
9716
PAGE 7-3
