7 PARTSLIST RM2042
POSITION DESCRIPTION MANUFACTOR TYPE PART NO.
PAGE 7-2
C41-1 CAPACITOR CERAM. SMD 0805 2n2F 10% X7R 50VDC MURATA GRM40 X7R 222 K 50 PT 328.328
C42-1 CAPACITOR CERAM. SMD 0805 2n2F 10% X7R 50VDC MURATA GRM40 X7R 222 K 50 PT 328.328
C43-1 CAPACITOR CERAM. SMD 0805 2n2F 10% X7R 50VDC MURATA GRM40 X7R 222 K 50 PT 328.328
C44-1 CAPACITOR CERAM. SMD 0805 2n2F 10% X7R 50VDC MURATA GRM40 X7R 222 K 50 PT 328.328
C45-1 CAPACITOR CERAM. SMD 0805 100nF 10% X7R 25VDC MURATA GRM40 X7R 104 K 25 PT 328.348
C46-1 CAPACITOR EMI KOND.EMI 2n2 100V MURATA NFM41R10C222T1 335.422
C47-1 CAPACITOR EMI KOND.EMI 2n2 100V MURATA NFM41R10C222T1 335.422
C48-1 CAPACITOR EMI KOND.EMI 2n2 100V MURATA NFM41R10C222T1 335.422
C49-1 CAPACITOR EMI KOND.EMI 2n2 100V MURATA NFM41R10C222T1 335.422
C50-1 CAPACITOR EMI KOND.EMI 2n2 100V MURATA NFM41R10C222T1 335.422
C51-1 CAPACITOR EMI KOND.EMI 2n2 100V MURATA NFM41R10C222T1 335.422
C52-1 CAPACITOR TANTALUM 3528 2u2F 20% 16VDC ERO CB 225020 M E17 334.028
C53-1 CAPACITOR TANTALUM 3528 2u2F 20% 16VDC ERO CB 225020 M E17 334.028
C54-1 CAPACITOR CERAM. SMD 0805 10nF 10% X7R 50VDC MURATA GRM40 X7R 103 K 50 PT 328.336
C55-1 CAPACITOR CERAM. SMD 0805 100nF 10% X7R 25VDC MURATA GRM40 X7R 104 K 25 PT 328.348
C56-1 CAPACITOR EMI KOND.EMI 2n2 100V MURATA NFM41R10C222T1 335.422
C57-1 CAPACITOR EMI KOND.EMI 2n2 100V MURATA NFM41R10C222T1 335.422
C58-1 CAPACITOR CERAM. SMD 1206 1u0F -20/80% Y5V 16VDC MURATA GRM42-6 Y5V 105 Z 16 PT10 328.806
C59-1 CAPACITOR CERAM. SMD 0805 100nF 10% X7R 25VDC MURATA GRM40 X7R 104 K 25 PT 328.348
C60-1 CAPACITOR CERAM. SMD 0805 10nF 10% X7R 50VDC MURATA GRM40 X7R 103 K 50 PT 328.336
C61-1 CAPACITOR CERAM. SMD 0805 1n0F 10% X7R 50VDC MURATA GRM40 X7R 102 K 50 PT 328.324
C62-1 CAPACITOR CERAM. SMD 1206 100nF 10% X7R 50VDC MURATA GRM42-6 X7R 104 K 50 PT 328.648
C63-1 CAPACITOR TANTALUM 3528 2u2F 20% 16VDC ERO CB 225020 M E17 334.028
C64-1 CAPACITOR ELECTROLYTIC SM 3u3F 20% 50VDC EUROPE CHEMICON Al-Chip-MKV 50V/3u3 M 333.073
C65-1 CAPACITOR TANTALUM 3528 2u2F 20% 16VDC ERO CB 225020 M E17 334.028
D1-1 DIODE RECTIFIER 1N4002 100V/1A MOTOROLA 1N4002(03/04/05/06/07)RL 25.100
D2-1 DIODE ZENER 20V 5% SMC SMC20A GENERAL INSTRUM TSMC20A-57 (-59) 341.430
D3-1 DIODE SMALL SIGNAL SOD-80 BAS32L PHILIPS BAS32L 340.032
D4-1 DIODE SMALL SIGNAL SOD-80 BAS32L PHILIPS BAS32L 340.032
D5-1 DIODE ZENER 5.1V 2% 0.5W SOD-80 TFK TZM/B5V1 340.417
D6-1 DIODE SMALL SIGNAL SOD-80 BAS32L PHILIPS BAS32L 340.032
D7-1 DIODE SMALL SIGNAL SOD-80 BAS32L PHILIPS BAS32L 340.032
D8-1 DIODE SMALL SIGNAL SOD-80 BAS32L PHILIPS BAS32L 340.032
F1-1 FUSE 2AF 5x20mm LITTELFUSE 217002. 45.556
FP1-1 EMI FERRITE BEAD 4.5x1.6x1.6mm 0.5A MURATA BLM 41 A 800 S PT 370.031
FP2-1 EMI FERRITE BEAD 4.5x1.6x1.6mm 0.5A MURATA BLM 41 A 800 S PT 370.031
J1-1 SOCKET SUB D 9 POLES PCB VERSION 2x 4-40 NUT EDA INC. 8TO-009SS-244T(144T,344T) 78.164
J2-1 SOCKET BNC PCB VERSION ROSENBERGER 51K102-400 A4 78.444
J3-1 SOCKET SUB D 9 POLES PCB VERSION 2x 4-40 NUT EDA INC. 8TO-009SS-244T(144T,344T) 78.164
J4-1 SOCKET SUB D 25 POLES PCB VERSION EDA INC. 8TO-025SS-244T 78.166
L1-1 COIL RF 8u2 SIEMENS B82412-A1822-M 337.135
L2-1 COIL RF 8u2 SIEMENS B82412-A1822-M 337.135
OC1-1 OPTO COUPLER MOC207, IL207 MOTOROLA MOC207 R1 (R2) 353.057
P1-1 PLUG 1/10" DIL SQ.PINS 6 POLES AMP 826656-3 78.340
P2-1 PLUG SUB D 9 POLES PCB VERSION 4-40 THREAD EDA INC. 8TO-009PS-241T 78.163
P3-1 PLUG 6 POLES HIRSCHMANN 973 887-100 78.315
P4-1 PLUG 2 POLES VERTICAL PCB VERSION JST B2B-ZR 78.448
P5-1 SMD PLUG (MALE) 16 POLES AMP 4-175643-6 375.005
P6-1 SMD PLUG (MALE) 16 POLES AMP 4-175643-6 375.005
P7-1 SMD PLUG (MALE) 16 POLES AMP 4-175643-6 375.005
P8-1 SMD PLUG (MALE) 16 POLES AMP 4-175643-6 375.005
P9-1 SMD PLUG (MALE) 16 POLES AMP 4-175643-6 375.005
Q2-1 TRANSISTOR AF NPN BC848B MOTOROLA BC848BLT1 (T3) 345.048
Q3-1 TRANSISTOR AF NPN BC848B MOTOROLA BC848BLT1 (T3) 345.048
Q4-1 TRANSISTOR LF BCP55-16 NPN SMD SIEMENS BCP55-16 345.355
Q5-1 TRANSISTOR AF NPN BC848B MOTOROLA BC848BLT1 (T3) 345.048
Q6-1 TRANSISTOR PNP BCP52-16 1.5W PHILIPS BCP52-16 346.352
Q7-1 TRANSISTOR AF NPN BC848B MOTOROLA BC848BLT1 (T3) 345.048
Q8-1 TRANSISTOR AF NPN BC848B MOTOROLA BC848BLT1 (T3) 345.048
Q9-1 TRANSISTOR AF SMALL SIGN SOT23 BC858B MOTOROLA BC858BT1 (T3) 345.058
R2-1 RESISTOR SMD 0805 100k OHM 5% 0.1W ROHM MCR 10 EZH J 104 302.072
R3-1 RESISTOR SMD 0805 2k2 OHM 5% 0.1W ROHM MCR 10 EZH J 222 302.052
R4-1 RESISTOR SMD 0805 100k OHM 5% 0.1W ROHM MCR 10 EZH J 104 302.072
R5-1 RESISTOR SMD 0805 100 OHM 5% 0.1W ROHM MCR 10 EZH J 101 302.036
R6-1 RESISTOR SMD 0805 100k OHM 5% 0.1W ROHM MCR 10 EZH J 104 302.072
R7-1 RESISTOR SMD 0805 47k OHM 5% 0.1W ROHM MCR 10 EZH J 473 302.068
R8-1 RESISTOR SMD 0805 10k OHM 5% 0.1W ROHM MCR 10 EZH J 103 302.060
R9-1 RESISTOR SMD 0805 27k OHM 5% 0.1W ROHM MCR 10 EZH J 273 302.065
R10-1 RESISTOR SMD 0805 47k OHM 5% 0.1W ROHM MCR 10 EZH J 473 302.068
R11-1 RESISTOR SMD 0805 27k OHM 5% 0.1W ROHM MCR 10 EZH J 273 302.065
R12-1 RESISTOR SMD 0805 10k OHM 5% 0.1W ROHM MCR 10 EZH J 103 302.060
R13-1 RESISTOR SMD 0805 220k OHM 5% 0.1W ROHM MCR 10 EZH J 224 302.076
R14-1 RESISTOR SMD 0805 220k OHM 5% 0.1W ROHM MCR 10 EZH J 224 302.076
R15-1 RESISTOR SMD 0805 220k OHM 5% 0.1W ROHM MCR 10 EZH J 224 302.076
9716
