SAIPA 141 / Maintaining and repairing manual Body and trimming
2- After that open the door hinge bolt and
remove the door.
For assembling do the above mentioned
inversely.
For regulating the tolerances between the
door and the body, loose the hinges bolts
and regulate the door. Then bolts must be
tightened.
Tightening torques for the hinges bolts are
as follows:
16-23N.m (1.6-2.3 Kg.m)
Disassembling the front door body
1- First of all remove the mounting lever pin
by the hammer.
Assembling and disassembling of parts
