27
SAIPA 141 / Maintaining and repairing manual Body and trimming
Disassembling the Rear door quarter
window glass:
First detach the trimming and all the attach-
ments. Then remove the center guide by
opening the nuts and bolts.
Move the rear part of the rear door down-
ward and detach the power window brack-
et.
Assembling and disassembling the lock
latches:
You can open the latch by opening the de-
picted two bolts and by tightening these
bolts, the latch will be tight. Be aware that
after assembling the door should be closed
moderately. Be cautious that you can regu-
late the latch by losing the hatch bolts.
First of all you should look at the gap be-
tween two bodies. If the gap is in proper
dimension, regulate the door by moving the
latch.
Tightening torque for the lock latch is as fol-
low:
18-27 N.m (1.8-2.7 Kg.m)
Assembling and disassembling of parts
