Saito FA-150 - Page 20

No. Description Qty.
01 Cylinder (left) 1
06 Piston 1
07 Piston pin 1
08 Piston pin retainer 2
09 Piston ring 1
10 Connecting rod 1
14 Cylinder screw set 1 set
15 Crankcase 1
17 Rear cover 1
19 Breather nipple 1
20 Front bearing 1
22 Rear bearing 1
23 Crankshaft 1
24 Pinion (crankshaft) 1
25 Pinion gearpin
26 Collar (crankshaft) 1
27 Taper collet & drive flange 1 each
28 Prop washer & nut 1 set
29 Prop nut-spinner
30 Prop nut-electric starter
31 Crankcase screw set 1 set
32 Engine gasket set 1 set
33 Cam gear housing 1
35 Cam gear 1
36 Cam gear shaft 1
37 Steel washer set 1 set
38 Tappet 2
No. Description Qty.
39 Pushrod 2
40 Pushrod cover & rubber seal 2 each
41 Rocker arm 2
42 Rocker arm screw & nut 2 each
43 Rocker arm pin 2
44 Rocker arm bracket (left) 1
45 Rocker arm bracket (right) 1
46 Valve (in & out) 2
47 Valve spring & keeper & retainer 2 each
48 Valve retainer
49 Rocker arm cover 2
68 Checkvalve (in & out) 1 pair
69 Intake manifold 1
74 Muffler 1
75 Muffler manifold 1
77 Muffler gasket 5
80 Muffler nut 2
89 Idle needle valve 1
821 Carburetor complete 1 set
831 Carburetor body assembly 1 set
84 Spray bar assembly
85 High speed needle valve 1
87 Throttle barrel assembly 1 set
91 Carburetor gasket set 1 set
93 Intake velocity stack 1 set
102 Fuel pump system complete 1 set
110 Anti-loosening nut 1
31
33
36
38
37
32
27
06
07
24
09
46
14
32
69
87
93
92
91
44
68
47
74
75
26
28
110
10
15
01
821
102
20
35
40
39
08
22
23
25
32
17
31
19
68
14
45
48
41
84
85
831
80
14
32
49
42
43
Fuel Pump System Complete
(Optional)
choke
89
Figure 9
P A R T S L I S T
