CHS2 Series

ELECTRICAL

CONNECTION

5.1 Additional Grounding Cable

Electrical connection must only be operated by professional technicians. Before connection, necessary

protective equipment must be employed by technicians, including insulating gloves, insulating shoes and safety

helmet.

WARNING

· Connect this additional grounding cable before other electrical connection.

Note: The additional cable and OT/DT terminal should be prepared by user themselves.

Figure 5.1

Preparing additional grounding cable

1. Heat shrink tubing 2. OT/DT terminal
