SAJ M2 Series - Page 8

M2 Series Micro-inverter
9
10
Overvoltage Category
ⅡI
Total Harmonic Distortion [THDi]
<3%
Maximum Units per 10AWG Branch
4
3
3
3
Efficiency
Peak Efficiency
97.00%
CEC Efficiency
96.00%
Mechanical Data
Operating Temperature Range
-40℃ to +60℃ (45℃ to 60℃ with derating)
Communication
Wi-Fi / Bluetooth
Cooling Method
Natural Convection
Ambient Humidity
0-100% non-condensing
Altitude
2000m
Noise [dBA]
＜20
Ingress Protection
IP67
Dimensions (W x H x D) [mm]
333*225*40
Weight [kg]
5.8kg
Warranty
12 Years
Applicable Standard
EN62109-1/2, EN61000-6-1/2/3/4, EN50438, EN50549, C10/11, IEC62116, IEC61727,
RD1699,CEI 0-16, CEI O-021, AS4777.2, NBR16149, NBR 16150 VDE-AR-N 4015, VDE
0126-1-1, RoSH
