SAJ R5-10K-T2 User Manual

R5 Series
- 16 -
R5-13K/15K/17K/20K-T2
Type
R5-13K-T2
R5-15K-T2
R5-17K-T2
R5-20K-T2
Input (DC)
Max. PV Array Power [Wp]@STC
19500
22500
25500
30000
Max. DC Voltage [V]
1100
MPPT Voltage Range [V]
160-950
180-950
Nominal DC Voltage [V]
600
Start Voltage [V]
180
200
Min. DC Voltage [V]
160
180
Max. DC Input Current [A]
25/12.5
25/25
Max. DC Short Current [A]
30/15
30/15
Number of DC Connection Sets per MPPT
2/1
2/2
Number of MPPT
2
DC Switch
Integrated
Output (AC)
Rated AC Power [W]
13000
15000
17000
20000
Max. AC Power [VA]*
1
14300
16500
18700
22000
Rated AC Current [A]@230Vac
18.9
21.8
24.7
29.0
Max. AC Current [A]
21.7
25.0
28.4
33.4
Current Inrush [A]
77
90
Max. AC Fault Current [A]
52
63
Max. AC Over Current Protection [A]
57.7
71.1
Nominal AC Voltage/ Range [V]
220/380,230/400,240/415;180-280/312-485
Grid Frequency/ Range [Hz]
50,60/45-55,55-65
Power Factor [cos φ]
0.8 leading~0.8 lagging
Total Harmonic Distortion [THDi]
< 2%
Feed-in
3L+N+PE
Efficiency
Max. Efficiency
98.7%
98.8%
Euro Efficiency
98.4%
98.46%
MPPT Accuracy
>99.5%
Protection
Internal Over-voltage Protection
Integrated
DC Insulation Monitoring
Integrated
DCI Monitoring
Integrated
GFCI Monitoring
Integrated

SAJ R5-10K-T2 Specifications

General

Brand	SAJ
Model	R5-10K-T2
Category	Inverter
Language	English
