Sakata SOB-50VA - Page 45

Light Commercial R410A on-off S13-01.01.13en
Notes: 1. Nominal cooling capacities are based on the following conditions:
Indoor temp: 27°CDB, 19°CWB; Outdoor temp: 35°CDB; Equivalent ref. Piping: 7.5m(horizontal)
2. Nominal heating capacities are based on the following conditions:
Indoor temp: 20°CDB; Outdoor temp: 7°CDB, 6°CWB; Equivalent ref. Piping: 7.5m(horizontal)
3. Actual noise level may differ, depending on the room structure, etc, since these noise values are from an anechoic
room.
Indoor Units. Ceiling & Floor
44
Model SIB-100TAY SIB-140TAY
Power supply V-ph-Hz 380~415-3-50 380~415-3-50
Cooling
Capacity Btu/h 36000 48000
Input W 3737 5128
EER 2.81 2.73
Heating
Capacity Btu/h 40000 52000
Input W 4286 5376
COP 2.8
2.79
Indoor fan motor
Model
YSK80-4A-2
YSK59-4D-4
Qty 1 2
Input W 159/142/130 102/98/96
Capacitor uF 3.5uF/450V 2.5uF/450V
Speed(Hi/Mi/Lo) r/min 1290/1170/1060 1230/1130/1070
Indoor coil
Number of rows 3 3
Tube pitch(a)×row pitch(b) mm 21×13.37 25.4×22
Fin spacing mm 1.3 1.5
Fin type (code) Hydrophilic aluminum Hydrophilic aluminum
Tube outside dia. and type mm Φ7 Inner grooved copper tube
φ9.5 Inner grooved copper tube
Coil length× height×width mm 1095×252×40.11 1360×254×66
Number of circuits 6 5
Indoor air flow(Hi/Mi/Lo)
m
3
/h
1400/1200/1000 2000/1800/1600
Indoor noise level (sound pressure) dB(A) 45/43/40 50/47/45
Indoor unit
Dimension (W×H×D) mm 1280×203×660 1670×240×680
Packing (W×H×D) mm 1327×238×739 1715x273x760
Net/Gross weight kg 35/42 46/53
Refrigerant type R410A R410A
Design pressure MPa 4.2/1.5 4.2/1.5
Refrigerant piping Liquid side/Gas side mm 12.7/19 12.7/19
Drainage water pipe diameter mm OD25 OD25
Controller RG36C/BG(C)E RG36C/BG(C)E
Operation temperature
℃
17-30 17-30
