2. SYMBOLS AND MARKING
Warning – pay attention Additional information
Apply the auxiliary label on the unit (on an easily accessible location) or on the dashed location of the technical manual in order to keep the im-
portant information about the unit.
Figure. 2.1. Technical label
1 - Logo; 2 - Product code (SKU); 3 - Product name; 4 - Technical data; 5 - Serial number; 6 - Production place.
Figure. 2.2. Indication for duct connection.
ODA - outdoor air; SUP - supply air; ETA - extract air; EHA - exhaust air.
Figure. 2.3. Technical label location and air duct indication
NOTE. Ducts are not the part of the unit.
