Salda Smarty 2X P 1.1 User Manual

6 | EN SMARTY XP v2020.3
SMARTY
2XP 1.1 2XP 1.2 3XP 1.1 3XP 1.2 4XP F2 1.1 4XP F2 1.2
L [mm] 1010 1010 1228 1228 1228 1228
W [mm] 590 590 690 690 690 690
H [mm] 250 250 324 324 324 324
øD [mm] 125 125 160 160 160 160
øDa [mm] 160 160 150 150 150 150
F [mm] 39 39 48 48 48 48
ød G1/2 G1/2 G1/2 G1/2 G1/2 G1/2
øda G3/8 G3/8 G3/8 G3/8 G3/8 G3/8
A1 [mm] 21 21 21 21 21 21
A2 [mm] 1047 1047 1268 1268 1268 1268
A3 [mm] 21 21 21 21 21 21
E1 [mm] 29 29 37 37 37 37
E2 [mm] 532 532 611 611 611 611
E3 [mm] 29 29 37 37 37 37
d1 [mm] 379 379 408 408 408 408
d2 [mm] 211 211 271 271 271 271
da1 [mm] 326 326 409 409 409 409
da2 [mm] 684 684 817 817 817 817
D1 [mm] 115 115 128 128 128 128
D2 [mm] 360 360 429 429 429 429
D3 [mm] 115 115 128 128 128 128
G1 [mm] 113 113 148 148 148 148
G2 [mm] 136 136 170 170 170 170
Weight [kg] 40 40 53 53 53 53
4.3. TECHNICAL DATA
SMARTY
2XP 1.1 2XP 1.2 3XP 1.1 3XP 1.2 4XP F2 1.1 4XP F2 1.2
Exhaust air fan
phase/voltage [50 Hz/VAC] 1/230 1/230 1/230 1/230 1/230 1/230
SRZHUFXUUHQW [kW/A] 0,05/0,4 0,05/0,4 0,09/0,75 0,09/0,75 0,17/1,35 0,17/1,35
speed [min
-1
] 4525 4525 3200 3200 4120 4120
control input [VDC] 0-10 0-10 0-10 0-10 0-10 0-10
protection class IP 44 IP 44 IP 54 IP 54 IP54 IP54
Supply air fan
phase/voltage [50 Hz/VAC] 1/230 1/230 1/230 1/230 1/230 1/230
SRZHUFXUUHQW [kW/A] 0,05/0,4 0,05/0,4 0,09/0,75 0,09/0,75 0,17/1,35 0,17/1,35
speed [min
-1
] 4525 4525 3200 3200 4120 4120
control input [VDC] 0-10 0-10 0-10 0-10 0-10 0-10
protection class IP 44 IP 44 IP 54 IP 54 IP54 IP54
7RWDOSRZHUFXUUHQWFRQVXPSWLRQ
[kW/A] 0,10/0,85 0,10/0,85 0,17/1,55 0,17/1,55 0,34/2,7 0,34/2,7
Automatic control integrated miniMCB miniMCB basic miniMCB miniMCB basic miniMCB miniMCB basic
,QVXODWLRQRIZDOOV [mm] 20 20 30 30 30 30
([KDXVWDLU¿OWHU
(class, dimensions LxWxH)
[mm]
MPL 185x168x25
&RDUVH
MPL 225x195x25
&RDUVH
MPL 225x195x25
&RDUVH
6XSSO\DLU¿OWHU
(class, dimensions LxWxH)
[mm]
MPL 185x168x25
&RDUVH
MPL 225x195x25
&RDUVH
MPL 225x195x25
&RDUVH
Device protection class IP 34 IP 34 IP 34 IP 34 IP-34 IP-34
According to EN 13141-7.
$FRXVWLFGDWDFKHFNWKHSURGXFWSDJHRQZZZVDOGDOW
Not suitable for installation in living rooms: additional noise insulation required.
