STEP 4 & 5
Insert stem into frame main tube then adjust handlebar stem (16) to a proper position then using lock lever
(21) to fix. Pull cable (92) out from the stem tube for a certain length like step 4-1. Open safety screw (28)
on the top slider then insert handlebar (11) onto stem's bottom slider like step 4-1. Make cable (92) to go
through top slider and console's support tube then sliding top slider forward to a certain position like step
5. Assemble console with cable and fix it onto bracket: Unscrew console’s fixing screw (8) from the console.
Connect cable (92) with console (9) then fix console on the bracket by screw back 4 fixing screw (8). Note:
Be careful on the cable (92) do not be damage during it connect with the console to assemble on the
bracket.
