24 VS20WRF and VS20BRF Installer Manual
Installation – LCD Graphics
ICON FUNCTION
Hot Water (HW) indicator:
Unit has been configured for HW Timer.
Hot Water (HW) indicator:
Indicates that there is Hot Water demand.
HW Program mode indicator:
Indicates program is running.
HW Mode indicator:
Mode for 1 period of HW a day, from Program 1 ON
to Program 3 OFF.
HW Mode indicator:
Indicates continuously On.
HW Mode indicator:
Indicates continuously Off.
HW Mode indicator:
Indicates Boost +1hr override.
INSTALLATION
