21 VS20WRF and VS20BRF Installer Manual
Installation – Thermostat Mounting VS10RF
Check that the wiring is completed for:
1
2
Please use the screws
provided
Ensure the orientation
arrow is pointing upwards.
Power Terminals
Sensor Terminals (if applicable)
You are ready to secure the rear housing to the wall box
To Next Page
