5 VS20WRF and VS20BRF Installer Manual
System Overview - Configuration Options
Programmable Room
Thermostat (PRT)
* Grouping and timer option only available
when used with wiring centre.
1
UFH Manifold
Wiring Centre
Radiator
Boiler
Hot Water
TRV
Towel Rails
Group Control
Thermostat*
2
Group
Thermostat*
3
Timer
4
The unit can be configured to
either one of the following
