S e t u p P a r a m e t e r
C H A R G E C U R V E
B U L K C U R R E N T
2 0 A
Screen No.1 of the "Select Parameter - CHARGE CURVE" for BULK
CURRENT setting appears as shown on the left.. The Default Value of
20A will be displayed as “20” using 2 digits. There will be a blinking
cursor under the 1st digit (“2”). The 1st digit (“2”) will also blink. To
change the setting to the new value of 50A, the 2 digits will have to
be changed from “20” to “50” one by one as follows:
• Press the Up Key to scroll the 1
st
digit to “5”. Press the Enter
Key MOMENTARILY to select “5” for the 1
st
digit. The blinking
cursor will automatically move to the 2
nd
digit “0”. The 2
nd
digit
“0” will be blinking.
• As the 2
nd
digit of the new setting “50” is already “0”, there is
no need to change this value. Now, the overall numerical value
will be “50”. The cursor and “0” at the 2
nd
digit will be blinking.
• Press the Enter Key, HOLD for 3 to 4 sec and then release to
write the new value of 50A into the memory.
W r i t e s u c c e s s !
Flashes twice when writing is successful.
S e t u p P a r a m e t e r
C H A R G E C U R V E
* B U L K C U R R E N T
2 0 A
End of setting.
Press Back Key to go back to the previous level "Select Group -
CHARGE CURVE" or Up/Down Key to the other parameter(s) within
the Select "Parameter - CHARGE CURVE".
S e t u p P a r a m e t e r
C H A R G E C U R V E
* B U L K C U R R E N T
! 9 0 A
An exclamation sign ‘!’ is shown when the parameter is out of the
specied programming range. For example, if 90A was entered for
EVO-1212F / 1212F-HW (EVO-1212F / 1212F-HW (programmable
range is 0-60A), it will be out of range and an exclamation sign ‘!’ will
be displayed.
W r i t e f a i l u r e !
Flashes twice when there is a write failure.
Flashes twice when the set value is out of range. (90 A is out of range
for EVO-1212F).
Details of all the programmable parameters, their programmable ranges and default values are detailed in
Section 4.4 to 4.10.
