76 | SAMLEX AMERICA INC.
SECTION 4 | Parameter Setup
• Fault message “Input over current” will be displayed on the LCD screen, Blue LED marked “Status”
will be switched off and Red LED marked “Fault” will be switched on.
o The unit will be latched in OFF condition and will require manual reset by powering off the
unit, waiting for 1 min and then, powering on again
4.5.2.11.1 Programming Steps for Parameter “INPUT OC PROTECT”
ð ð
E V O - 1 2 1 2 F I n v e r t i n g
A C o u t p u t : 1 2 0 . 0 V
< 0 . 1 0 A
6 0 . 0 0 H z
Enter Key
Any Operating Mode Screen from
Fig 3.1 to 3.5
[Above screen is Screen 1 of Fig 3.2(a)]
Password 8052
See Section 4.3.1
For programmable options, see Table 4.6:
(i) Parameter Setup Screen No. 8 under Column 1
for EVO-
1212F/1212F-HW/1224F/1224F-HW
(ii) Parameter Setup Screen No. 10 under Column 2
for EVO-2212/3012/2224/4024
S e l e c t G r o u p
* C H A R G E C U R V E
ð
S e l e c t P a r a m e t e r
* I N P U T S E T T I N G
ð
S e l e c t P a r a m e t e r
I N P U T S E T T I N G
* D E F A U L T F R E Q
0 = 6 0 H z
S e l e c t P a r a m e t e r
I N P U T S E T T I N G
* I N P U T O C P R O T E C T
0 = I N V m o d e
Down Key x 1 time
Enter Key
P a s s w o r d k e y i n
0 0 0 0
ð
Enter Key
S e l e c t P a r a m e t e r
I N P U T S E T T I N G
* I N P U T O C P R O T E C T
0 = I N V m o d e
ð
Enter Key
4.5.2.12 INPUT RECOVERY
(Table 4.6: (i) Parameter Screen No. 9 under Column 1 for EVO-1212F/1212F-HW/1224F/1224F-HW
(ii) Parameter Setup Screen No. 11 under Column 2 for EVO-2212/3012/2224/4024)
This parameter determines how EVO will recover when AC input is made available while in “Battery low voltage!” or
“Battery ultra low voltage!” fault conditions (Srl. Nos. 1 and 2 respectively of TABLE 7.1). The following 2 options are
available under this parameter:
• Option “0=Buffered” (This is the default option)
• Option “1=Direct”
When the EVO is in “Battery low voltage!” condition (Section 7, Srl 1 of TABLE 7) or in “Battery ultra low voltage!”
condition (Section 7, Srl. 2 of TABLE 7.1) and if AC input is made available before expiry of time set by parameter “LV
CUT OFF TIME” (Section 4.4.2.11), the “Battery low voltage!” / “Battery ultra low voltage!” fault conditions will be
cleared and EVO Inverter Charger will recover based on the following 2 options:
a) Option 0=Buffered (Default): Under this option, the unit will initially start in “Inverting Mode”,
synchronize with the AC input and then transfer to “Charging Mode”. However, if a user programs the
value of “BATTERY LOW VOLTAGE” very close to the “Battery ultra low voltage!” fault threshold of 9V
for 1 ms for EVO-1212F/1212F-HW/2212 / 3012 or 18V for 1 ms for EVO-1224F/1224F-HW/2224 / 4024
(Table 7.1), a larger load / larger starting surge on the inverter may drag the battery voltage to 9V / 18V or
below for 1 ms and trigger “Battery ultra low voltage!” fault. Under this condition, the user may change
to Option 1=Direct
b) Option 1=Direct: Under this option, the unit will directly start in “Charging Mode”
(i) Down Key x 7 times for EVO-
1212F/1212F-HW/1224F/1224F-HW
(ii) Down Key x 9 times for EVO-
2212/3012/2224/4024
To Next Page
