SAMLEX AMERICA INC. | 77
SECTION 4 | Parameter Setup
4.5.2.12.1 Programming Steps for Parameter “INPUT RECOVERY”
ð ð
E V O - 1 2 1 2 F I n v e r t i n g
A C o u t p u t : 1 2 0 . 0 V
< 0 . 1 0 A
6 0 . 0 0 H z
Enter Key
Any Operating Mode Screen from
Fig 3.1 to 3.5
[Above screen is Screen 1 of Fig 3.2(a)]
Password 8052
See Section 4.3.1
For programmable options, see Table 4.6:
(i) Parameter Setup Screen No. 9 under Column 1
for EVO-
1212F/1212F-HW/1224F/1224F-HW
(ii) Parameter Setup Screen No. 11 under Column 2
for EVO-2212/3012/2224/4024
S e l e c t G r o u p
* C H A R G E C U R V E
ð
S e l e c t P a r a m e t e r
* I N P U T S E T T I N G
ð
S e l e c t P a r a m e t e r
I N P U T S E T T I N G
* D E F A U L T F R E Q
0 = 6 0 H z
S e l e c t P a r a m e t e r
I N P U T S E T T I N G
* I N P U T R E C O V E R Y
0 = B u f f e r e d
Down Key x 1 time
Enter Key
P a s s w o r d k e y i n
0 0 0 0
ð
Enter Key
S e l e c t P a r a m e t e r
I N P U T S E T T I N G
* I N P U T R E C O V E R Y
0 = B u f f e r e d
ð
Enter Key
4.6 GROUP 3 PARAMETER SET UP: INPUT LOW LIMIT
4.6.1 Programming Ranges and Default / Factory Preset Values of Parameters under Group 3 -
INPUT LOW LIMIT
Table 4.7 gives details of programming ranges and default values of parameters under Group 3 - INPUT LOW LIMIT.
Refer to Fig 4.3 under Section 4.1.3.2 for Menu Map for navigating through the various parameters under this Group 3.
Table 4.7 Group 3 Parameter Set Up: INPUT LOW LIMIT (Refer to Menu Map at Fig 4.3, Section 4.1.3.2)
Parameter
Setup Screen
No.
(Column 1)
Parameter
(Column 2)
Setting range
EVO-1212F
EVO-1212F-HW
(Column 3)
EVO-2212
(Column 4)
EVO-3012
(Column 5)
EVO-1224F
EVO-1224F-HW
(Column 6)
EVO-2224
(Column 7)
EVO-4024
(Column 8)
1 RESET VOLTAGE
60.00 - 120.0V
(Default:105.0V)
2 CUT OFF VOLT 1
60.00 - 120.0V
(Default: 100.0V)
3 DETECT TIME 1
0 - 2000 cycles
(Default: 300 cycles)
4 CUT OFF VOLT 2
60.00 - 120.0V
(Default: 95.0V)
5 DETECT TIME 2
0 - 2000 cycles
(Default: 60 cycles)
6 CUT OFF VOLT 3
60.00 - 120.0V
(Default: 90.0V)
7 DETECT TIME 3
0 - 2000 cycles
(Default: 1 cycle)
4.6.2 Description of Parameters Under Group 3 – INPUT LOW LIMIT
4.6.2.1 RESET VOLTAGE (Table 4.7, Parameter Setup Screen No.1)
This is the reset voltage at which the unit will revert to "Charging Mode" after it has switched over to "Inverting Mode"
due to input voltage falling to "CUT-OFF VOLT 1 / CUT-OFF VOLT 2 / CUT-OFF VOLT3".
(i) Down Key x 8 times for EVO-
1212F/1212F-HW/1224F/1224F-HW
(ii) Down Key x 10 times for EVO-
2212/3012/2224/4024
To Next Page
