84 | SAMLEX AMERICA INC.
SECTION 4 | Parameter Setup
TABLE 4.9 Group 5 Parameter Set Up: OTHER FUNCTION (Refer to Menu Map at Fig 4.4, Section 4.1.3.3
Parameter Setup
Screen Nos. for
EVO-1212F/
1212F-HW/ 1224F/
1224F-HW
(Column 1)
Parameter Setup
Screen Nos. for
EVO-2212/ 3012/
2224/ 4024
(Column 2)
Parameter
(Column 3)
Setting range
EVO-1212F
EVO-1212F-HW
(Column 4)
EVO-
2212
(Column 5)
EVO-
3012
(Column 6)
EVO-1224F
EVO-1224F-HW
(Column 7)
EVO-
2224
(Column 8)
EVO-
4024
(Column 9)
1 1
POWER SAVING
0 = Disable ; 1 = Enable
(Default: 0 = Disable)
2 2
ENTER POINT
4 - 50W
(Default:
6W)
4 - 50W
(Default:
6W)
4 - 50W
(Default:
8W)
4 - 50W
(Default:
6W)
4 - 50W
(Default:
6W)
4 - 50W
(Default:
8W)
3 3
WAKE UP POINT
5 - 50W
(Default:
7W)
5 - 50W
(Default:
7W)
5 - 50W
(Default:
10W)
5 - 50W
(Default:
7W)
5 - 50W
(Default:
7W)
5 - 50W
(Default:
10W)
4 4
REMOTE SWITCH
0 = Button Type , 1 = Switch Type
(Default: 0 = Button Type)
– 5
RELAY FUNCTION
0 = Charger / Other
1 = Normal / Fault
2 = Generator 0
3 = Generator 1
4 = Generator 2
(Default:2 = Generator 0)
0 = Charger / Other
1 = Normal / Fault
2 = Generator 0
3 = Generator 1
4 = Generator 2
(Default:2 = Generator 0)
5 6
COMM ID
1 - 255
(Default: 1)
6 7
BUZZER
0 = OFF ; 1 = ON
(Default: 1 = ON)
7 8
DISCHARGE BEEP
0 = OFF ; 1 = ON
(Default: 0 = OFF)
8 9
DEFAULT RESET
0 = No ; 1 = Yes
(Default: 0 = No)
9 10
DATALOG TIME
0 = Disable; 1 = 1 sec; 2 = 10 sec; 3 = 30 sec;
4 = 1 min; 5 = 5 min; 6 = 10 min
(Default: 1 = 1 sec)
10 11
PARAMETER SAVE
0 = No ; 1 = Yes
(Default: 0 = No)
11 12
TEMP UNIT
0 = °C ; 1 = °F
(Default: 0 = °C)
12 13
PASSWORD DISABLE
0 = No , 1 = Yes
(Default: 0 = No)
NOTE for Table 4.9:
1. Parameter "RELAY FUNCTION" (Parameter Setup Screen No. 5 under Columns 2 & 3) is available only for
EVO-2212 / 3012F/ EVO-2224 / 4024.
